MONROE MA835 Part Description
Manufacturer
Product Description
Max-Air Air Adjustable Air Shock Absorber Pack of 2
Features & Benefits
- MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
- EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
- EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
- BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
MONROE MA835 Specifications
Product Attributes
| Compressed Length | 16.9 IN |
| Extended Length | 28.26 in |
| Travel Length | 11.36 in |
| Lower Mount Code | LS38 |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.1/2" Sleeve OAL |
| Upper Mount Code | LS38 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 38.1MM Sleeve OAL |
| Dust Shield Included | No |
| Includes Bump Stop | No |
| Hydraulic Lockout | No |
| Parts Pack(s) | None |
| Part Description | Air Shock Absorber |
| Internal Rebound Bumper | No |
| Compressed Length | 429.3 MM |
| Extended Length | 717.8 MM |
| Travel Length | 288.5 MM |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598163042 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE MA835 Part Interchanges
| Brand | Part Number |
|---|---|
| Ford | 9L3Z18124BE, 9L3Z18124CE, 9L3Z18124DE, 9L3Z18124EE, 9L3Z18124FE, 9L3Z18124M, 9L3Z18125A, 9L3Z18125B, 9L3Z18125C, 9L3Z18125D, 9L3Z18125E, 9L3Z18125F, AL3Z18124A, AL3Z18124AA, AL3Z18124BA, AL3Z18124CA, AL3Z18124DA, AL3Z18124EA, AL3Z18124FA, AL3Z18124GA, AL3Z18124RB, AL3Z18124SB, AL3Z18124TA, AL3Z18125D, AL3Z18125E, AL3Z18125G, AL3Z18125H, AL3Z18125K, AL3Z18125L, BL3Z18124C, BL3Z18124F, BL3Z18124H, BL3Z18124J, BL3Z18125C, BL3Z18125F, BL3Z18125H, BL3Z18125J, BL3Z18125K, BL3Z18125L, CL3Z18124A, CL3Z18124B, EL3Z18124A, EL3Z18124B, EL3Z18124C, EL3Z18124D, EL3Z18124E, EL3Z18124F, EL3Z18124G, EL3Z18124H, EL3Z18124J, EL3Z18124K, EL3Z18124L |
| NAPA Shocks | MA835 |
MONROE MA835 Fits Vehicles
- Ford Lobo (2009-2014)
- Ford F-150 (2009-2014)
MONROE MA835 Cross References
We have 2 alternatives for the MA835 by MONROE:
