Monroe 65552 - Magnum Suspension Shock Absorber
$9399
In stock
limited availability at this price!
. Learn more
MONROE part description
Monroe Magnum 65552 Shock Absorber
Product Description
Magnum Suspension Shock Absorber
Features & Benefits
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve helps prevent walkout for improved quality (most applications); resistance arc welds, and/or arc welds up to 360° for durability
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve helps prevent walkout for improved quality (most applications); resistance arc welds, and/or arc welds up to 360deg for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
- BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
Product Attributes
| 9791 | LS62 |
| 9789 | LS61 |
| Compressed Bumper Stop | No |
| Dust Shield | Yes |
| Extended Bumper Stop | No |
| Extended Hydraulic Lockout | Yes |
| Body Diameter | 2.38 IN |
| Compressed Length | 15.56 IN |
| Extended Length | 24.73 in |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16mm Sleeve ID X 2 9/16" Sleeve OAL |
| Parts Pack(s) | None |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Travel Length | 9.52 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16mm Sleeve ID X 4" Sleeve OAL |
| Compressed Length | 395.2 MM |
| Extended Length | 628.1 MM |
| Travel Length | 241.8 MM |
| 9908 | No |
| Body Diameter | 60.5 MM |
| Dust Shield Included | Yes |
| 9783 | No |
| 9792 | Yes |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598242648 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
Part Interchanges
Fits Vehicles
- Mack MD7 (2021-2022)
- Mack MD6 (2021-2022, 2024)
- Mack Anthem (2021-2022)
- Volvo VNL (2021-2022)
- Volvo VNR (2021-2022)
Monroe products are built for the road ahead. Since its founding in 1916, Monroe® has been known for its world-class solutions that are precision-engineered and meticulously tested with the specific vehicle's ride and handling profile in mind. As the leading supplier of Original Equipment ride control products to global automotive manufacturers, Monroe helped establish the benchmarks of handling and ride excellence in every stage of a vehicle's life. Whether you're upgrading your truck, converting its suspension, or restoring its original state, Monroe has got you covered. It offers the best-in-class shocks, strut assemblies, steering stabilizers, conversion kits, lift support, and many other suspension components that will help enhance your safety and driving experience.
