(888) 312-8812 Login SignupREACH COOLING 42-10406 mack-volvo ch-chn-chu-cv-cu series 2008-2010
Tap to view 1 more
$1,30999
Limited availability at this price!
In Stock
Get it by Friday, Jan 9
REACH COOLING 42-10406 Part Description
Manufacturer
Product Description
mack-volvo ch-chn-chu-cv-cu series 2008-2010
Application Summary
mack-volvo ch-chn-chu-cv-cu series 2008-2010
Features & Benefits
- Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
- Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
- Our fin edges are folded for increased stability and heat disbursement properties.
- Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
- Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
- Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
- Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
- We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
- Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
- Folded fin edges increase stability and heat disbursement properties.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
- Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
mack/volvo ch/chn/chu/cv/cu series 2008-2010
| Make | Volvo, Mack |
| Model | CH, CHN, CHU, CV, CU |
| Year | 2008, 2009, 2010 |
REACH COOLING 42-10406 Specifications
Product Attributes
| Transmission Oil Cooler Distance between Fittings | 11-1/2 IN |
| Outlet Diameter | 2 1/2 IN |
| Core Height | 39 3/8 IN |
| Core Width | 35-1/8 IN |
| Inlet Diameter | 2-1/2 IN |
| Core Thickness | 2 1/16 IN |
| Core Width | 868 MM |
| Outlet Location | Bottom Right |
| Inlet Diameter | 64 MM |
| Radiator Cap Included | No |
| Transmission Oil Cooler Distance between Fittings | 292 MM |
| Engine Oil Cooler Included | No |
| Tank Material | PA66-GF30 |
| Core Material | Aluminum |
| Down Flow Or Cross Flow Type | Down Flow |
| Transmission Oil Cooler Included | Yes |
| Inlet Location | Top Left |
| Frame Included | No |
Additional Information
| Country of Origin (Primary) | CN |
| Warranty Special | 12 Months |
| UPC | 06941099904456 |
| VMRS Code | 042002001 |
| UNSPSC | 25174002 |
REACH COOLING 42-10406 Part Interchanges
| Brand | Part Number |
|---|---|
| Keystone Auto Industries | HDC010194 |
| Northern Radiator | 239033, 239049, SCSI239033, SCSI239049 |
| OEM | 7326, LT1182, SRM1182 |
| Serck | FLA000625 |
| Vista Pro | 437228S |
| Active Radiator Supply Company | 7300-26, 7300-26ST, 730026, 730026PT, 730026PTR, 730026ST |
| Volvo Truck | 21000732, 21000733, 21095130, 21095132, 21504542, 21504554, 21593035, 21593041, 23017339, 2400730, 2400939, 2MF561M, 2MF568M, 376761661, 559049OEM, 621RA026, 85112702, 85125541, 8MK376761661, MAC24, MAC28, MK8240PTOOC, MKRP11821S2, N6414, N6414100, N6415, N6415100, R4583, R4583001, S5588, S5744, S5750, S7326, TR9033, TR9049, X7326, Y8076 |
| 1-800-Radiator | 2400939 |
| Mack | HDC010194PA |
| OSC | HD1182 |
| NAPA | NR4210406 |
| Superior Cooling Systems | 239049 |
| Lei Te | LT1182 |
REACH COOLING 42-10406 Fits Vehicles
- Volvo VHD (2008-2010)
- Mack CHU (2008-2010)
- Mack CHN (2006-2007)
- Mack GU8 (2008-2010)
- Mack GU7 (2008-2010)
REACH COOLING 42-10406 Cross References
We have 58 alternatives for the 42-10406 by REACH COOLING:
- 2MF561M
- NORTHERN RADIATOR 239033
- NORTHERN RADIATOR 239049
- OEM 21000732
- OEM 21000733
- OEM 21095130
- OEM 21095132
- OEM 21504542
- OEM 21504554
- OEM 21593035
- OEM 21593041
- OEM 23017339
- OEM 239033
- OEM 239049
- OEM 2400730
- OEM 2400939
- OEM 2MF561M
- OEM 2MF568M
- OEM 376761661
- OEM 437228S
- OEM 559049OEM
- OEM 621RA026
- OEM 730026
- OEM 7300-26
- OEM 730026PT
- OEM 730026PTR
- OEM 730026ST
- OEM 7300-26ST
- OEM 7326
- OEM 85112702
- OEM 85125541
- OEM 8MK376761661
- OEM HDC010194
- OEM LT1182
- OEM MAC24
- OEM MAC28
- OEM MK8240PTOOC
- OEM MKRP11821S2
- OEM N6414
- OEM N6414100
- OEM N6415
- OEM N6415100
- OEM R4583
- OEM R4583001
- OEM S5588
- OEM S5744
- OEM S5750
- OEM S7326
- OEM SCSI239033
- OEM SCSI239049
- OEM SRM1182
- OEM TR9033
- OEM TR9049
- OEM X7326
- OEM Y8076
- OSC HD1182
- SERCK FLA000625
- THERMAL SOLUTIONS MANUFACTURING 437228S
REACH COOLING 42-10406 Customer Reviews
No reviews yet
Be the first to review this product!
REACH COOLING 42-10406 Manufacturer Information
Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
