Name: Reach Cooling 42-10326 Kenworth Radiator Fits 2006 - 2008 T600-T660 40"x28.62"x2.62" Inl
SKU: 4210326
Price: 2041.49 USD
Availability: InStock

REACH COOLING part description

Kenworth Radiator Fits 2006 - 2008 T600/T660 40"x28.62"x2.62" Inlet:2.50" Top Left Outlet:2.50" Bottom Right,4 Row Core,UP1/2" tubes on 7/16" centers

Specifications

Height	40
Width	28.62
Thickness	2.62
Row	4
Inlet	2.5
Outlet	2.5

Make	Kenworth
Model	T600, T660, T800

Product Description

Kenworth Radiator Fits 2006 - 2008 T600-T660 40"x28.62"x2.62" Inl

Application Summary

Kenworth Radiator Fits 2006 - 2008 T600-T660 40"x28.62"x2.62" Inlet:2.50" Top Left Outlet:2.50" Bottom Right-4 Row Core-UP1-2" tubes on 7-16" centers

Features & Benefits

Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Folded fin edges increase stability and heat disbursement properties.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Our fin edges are folded for increased stability and heat disbursement properties.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Outlet Diameter	3 IN
Inlet Diameter	2.5 IN
Core Height	40 IN
Core Thickness	2 5/8 IN
Down Flow Or Cross Flow Type	Down Flow
Core Row Quantity	4
Frame Included	Yes
Tank Material	Brass
Core Width	28 3/4 IN
Core Material	Copper
Core Width	730.25 MM
Outlet Diameter	76.2 MM
Outlet Location	Lower Right
Inlet Diameter	64 MM
Core Height	1016 MM
Core Width	730.3 MM
Transmission Oil Cooler Included	No
Radiator Cap Included	Not Needed
Outlet Diameter	76 MM
Core Thickness	66.675 MM
Inlet Diameter	63.5 mm
Core Height	1016 MM
Inlet Location	Upper Left
Engine Oil Cooler Included	No
Core Thickness	66.7 MM

Additional Information

Country of Origin (Primary)	CN
Warranty Special	12 Months
UPC	06949521713072
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

REACH COOLING 42-10326 Cross Reference

We have 48 alternatives for the 42-10326 by REACH COOLING:

Fits Vehicles

Kenworth T400 (1995)
Kenworth W900 (1986-1997)
Kenworth T800 (1987-2007)
Kenworth T600A (1988-2007)
Kenworth T2000 (1999-2006)
Kenworth T300 (1996-1999)
