(888) 312-8812 Login SignupREACH COOLING 42-10171 MACK CH613 E6-E7 ENGINE
Tap to view 5 more
$67749
Limited availability at this price!
In Stock
Get it by Wednesday, Feb 18
REACH COOLING 42-10171 Part Description
Manufacturer
Product Description
MACK CH613 E6-E7 ENGINE
Application Summary
MACK CH613 E6-E7 ENGINE
Features & Benefits
- Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
- Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
- Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
- Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
- We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
- Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
- Our fin edges are folded for increased stability and heat disbursement properties.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
- Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
- Folded fin edges increase stability and heat disbursement properties.
- Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
- We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
- Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
- Our utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
| Core Material | Aluminum |
| Tank Material | Plastic |
| Thickness | 2 3/16 (Inches) |
Application Summary: Application Summary: Mack Trucks; Models: CH600 (2005-90), CS200P (1996), CX600 (2005), FDM700 (1994, 1996), MR600S (2003, 2000, 1989), R600ST (1985), R600S (1994)
| Make | Volvo, Mack |
| Model | CH |
| Year | 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004 |
REACH COOLING 42-10171 Specifications
Product Attributes
| Inlet Header Length | 1023.9 MM |
| Core Material | Aluminum |
| Inlet Header Width | 3.187 IN |
| Outlet Header Width | 3.187 IN |
| Core Row Quantity | 2 |
| Core Width | 39.37 IN |
| Inlet Diameter | 2 IN |
| Outlet Diameter | 2.5 IN |
| Down Flow Or Cross Flow Type | Down Flow |
| Frame Included | No |
| Transmission Oil Cooler Included | No |
| Outlet Header Length | 40.312 IN |
| Tank Material | Plastic |
| Core Height | 28.87 IN |
| Core Thickness | 2.25 IN |
| Engine Oil Cooler Included | No |
| Inlet Diameter | 50.8 mm |
| Outlet Header Width | 80.949 mm |
| Outlet Header Width | 81 MM |
| Inlet Location | Top Left |
| Outlet Diameter | 63.5 MM |
| Outlet Location | Bottom Left |
| Core Width | 1000.125 MM |
| Inlet Header Width | 80.949 mm |
| Core Height | 733.4 MM |
| Inlet Diameter | 51 MM |
| Radiator Cap Included | No |
| Core Thickness | 57.15 MM |
| Outlet Header Length | 1023.924 mm |
| Inlet Header Width | 81 MM |
| Inlet Header Length | 40.312 IN |
| Outlet Diameter | 63.5 MM |
| Core Thickness | 57.2 MM |
| Outlet Header Length | 1023.9 MM |
| Core Height | 733.425 MM |
| Inlet Header Length | 1023.924 mm |
| Core Width | 1000 MM |
| Surge Tank Included | No |
| Filler Neck Included | No |
Additional Information
| Country of Origin (Primary) | CN |
| Warranty Special | 12 Months |
| UPC | 06949521787875 |
| VMRS Code | 042002001 |
| UNSPSC | 25174002 |
REACH COOLING 42-10171 Cross References
REACH COOLING 42-10171 Fits Vehicles
- Mack FDM (1994-1996)
- Mack CX (2005)
- Mack RD (1994)
- Mack MR (1989, 2000, 2003)
- Mack CH (1990-2005)
- Mack R (1985)
- Mack CS200P Mid-Liner (1996)
REACH COOLING 42-10171 Customer Reviews
No reviews yet
Be the first to review this product!
REACH COOLING 42-10171 Manufacturer Information
Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
REACH COOLING 42-10171 Questions & Answers
No questions yet
Be the first to ask a question about this product!
