MONROE 555001 Magnum RV Suspension Shock Absorber

555001 by MONROE - Magnum RV Suspension Shock Absorber
MONROE
Tap to view 5 more

MSRP: $115.95

$44.49

Save $71.46

Limited availability at this price!

In Stock

Get it by Thursday, Jan 29
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 555001 Part Description

Manufacturer

MONROE

Product Description

Magnum RV Suspension Shock Absorber

Features & Benefits

  • FOR RECREATIONAL VEHICLES -- Designed to handle the demands of recreational vehicles that go on cross country adventures and trips close to home
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to improve performance (when required)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the bore provides more efficient and consistent control (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (when required)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 555001 Specifications

Product Attributes

Lower Mount Code S4
Upper Mount Code S4
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper Yes
Hydraulic Lockout No
Part Description Shock Absorber
Compressed Length 7.875 IN
Dust Shield Material Metal
Extended Length 11.875 in
Gas Charged Yes
Lower Mount Type Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Parts Pack(s) (2) P01134
Travel Length 4 in
Upper Mount Type Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Compressed Length 200 MM
Extended Length 301.6 MM
Travel Length 101.6 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Base of Stem

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598555014
VMRS Code 016008003
UNSPSC 25172011

MONROE 555001 Cross References

BrandPart Number
555001MM, MAE555001
AL-KO19176, 5200300
ALKO / KOBER5200300, 19176
BULLDOG HD SHOCKSHD1213-0656
Bulldog HDHD12130656
DEXTER CO19176, 5200300
DINA19176
Dayton Parts441555001
Dexter19176, 5200300
Gold Shock Absorber9131792
HAYNES922070
NAPA Shocks555001
