REACH COOLING part description

FREIGHTLINER/STERLING 2008 - Newer Cascadia

Make Freightliner
Model Cascadia
Year 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018

Product Description

FREIGHTLINER-STERLING 2008 - Newer Cascadia

Application Summary

FREIGHTLINER-STERLING 2008 - Newer Cascadia

Features & Benefits

  • We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
  • Our fin edges are folded for increased stability and heat disbursement properties.
  • Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
  • Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
  • Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
  • Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
  • Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
  • Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
  • Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
  • Folded fin edges increase stability and heat disbursement properties.
  • Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
  • Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
  • We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.

Product Attributes

Inlet Diameter 2-1/2 IN
Core Height 42-1/8 IN
Core Thickness 2 3/16 IN
Core Width 38 1/2 IN
Transmission Oil Cooler Distance between Fittings 12 IN
Outlet Diameter 2 1/2 IN
Outlet Location Bottom Right
Tank Material PA66-GF30
Inlet Diameter 64 MM
Core Height 1067 MM
Radiator Cap Included No
Transmission Oil Cooler Included Yes
Engine Oil Cooler Included No
Inlet Location Top Left
Frame Included No
Transmission Oil Cooler Distance between Fittings 305
Core Material Aluminum
Down Flow Or Cross Flow Type Down Flow

Additional Information

Warranty Special 12 Months
Country of Origin (Primary) CN
UPC 06941099904210
VMRS Code 042002001
UNSPSC 25174002

Part Interchanges

Fits Vehicles

  • Freightliner Cascadia (2008-2017)

Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
