Name: Reach Cooling 61-1025 Charge Air Cooler
SKU: 611025
Price: 1053.49 USD
Availability: InStock

REACH COOLING part description

Product Description

Charge Air Cooler

Application Summary

Peterbilt:87-2002 357/85-87 359/86-90 362/88-93 375/87-94 377/88-94 378/87-94 379

Features & Benefits

Header Plate Bond: We use a wider angle header plate bond to eliminate the risk of header cracking.
Flat Tube Wall Thickness: Flat tube wall thickness is no less than .55mm to maximize ability to withstand added pressure.
Deep Extrusion Header: Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion.
Reach charge air coolers are built to withstand the pressures of long hauls. From the product design to the package it is shipped in, every consideration is taken to ensure longevity and peak performance.
7 Layer Packaging: Each charge air cooler is packaged in a heavy duty, 7 layer corrugated box to ensure best protection during transit.
Reinforced Aluminum Alloy: Header reinforced with aluminum bronze to increase strength by 50%.
Reinforcement Rib: Tubes feature a reinforcing rib to increase material strength.

Product Attributes

Inlet Header Width	67 mm
Outlet Header Width	67 mm
Core Thickness	56 MM
Inlet Outside Diameter	117 MM
Outlet Header Length	691 mm
Outlet Location	Upper Right
Inlet Location	Upper Left
Core Height	631.8 MM
Outlet Outside Diameter	4 5/8 IN
Core Length	666 MM
Inlet Header Length	27.187 in
Core Row Quantity	1
Inlet Header Width	2.625 in
Outlet Header Width	2.625 in
Outlet Header Length	27.187 in
Core Length	26.25 IN
Core Thickness	2.187 IN
Inlet Outside Diameter	4.625 IN
Type	Harmonica-shaped tube
Inlet Header Length	691 mm
Core Material	Aluminum
Outlet Outside Diameter	117.5 MM
Core Height	24 7/8 IN

Additional Information

Country of Origin (Primary)	CN
UPC	06949521756154

Part Interchanges

REACH COOLING 61-1025 Cross Reference

We have 83 alternatives for the 61-1025 by REACH COOLING:

Fits Vehicles

Peterbilt 379 (1987-1991, 1993-1994)
Peterbilt 377 (1987-1994)
Peterbilt 362 (1986-1990)
Peterbilt 359 (1985-1987)
Peterbilt 375 (1988-1991, 1993)
Peterbilt 357 (1987-1990, 1992-1995, 2002)
Peterbilt 378 (1988-1994)
