Name: Reach Cooling 42-10334 PERTERBILT CONVENTIONALS 1988-2007 Core Dims 36.25 x 34.62 x 2.62
SKU: 4210334
Price: 1992.49 USD
Availability: InStock

REACH COOLING part description

PERTERBILT CONVENTIONALS 1988-2007 Core Dims 36.25" x 34.62" x 2.62", Inlet 2.50" Left, Outlet 3.00 Bottom Right, UP 1/2" tube on 7/16" centers, 4 row core

Specifications

Height	36.25
Width	34.62
Thickness	2.62
Row	4
Inlet	2.5
Outlet	3

Make	Peterbilt
Model	Conventionals

Product Description

PERTERBILT CONVENTIONALS 1988-2007 Core Dims 36.25 x 34.62 x 2.62

Application Summary

PERTERBILT CONVENTIONALS 1988-2007 Core Dims 36.25 x 34.62 x 2.62quot;- Inlet 2.50" Left- Outlet 3.00 Bottom Right- UP 1-2" tube on 7-16" centers- 4 row core

Features & Benefits

Folded fin edges increase stability and heat disbursement properties.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Our fin edges are folded for increased stability and heat disbursement properties.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Core Row Quantity	4
Frame Included	No
Tank Material	Brass
Core Width	35 1/4 IN
Down Flow Or Cross Flow Type	Down Flow
Outlet Diameter	3 IN
Core Thickness	2 5/8 IN
Core Height	36.25 IN
Core Material	Copper
Inlet Diameter	2 1/2 IN
Inlet Diameter	63.5 MM
Engine Oil Cooler Included	No
Core Thickness	66.675 MM
Core Width	895.35 MM
Core Width	895.4 MM
Radiator Cap Included	No
Core Height	920.75 MM
Outlet Diameter	76.2 MM
Core Thickness	66.7 MM
Inlet Location	Top Left
Inlet Diameter	63.5 mm
Core Height	921 MM
Transmission Oil Cooler Included	No
Outlet Location	Bottom Right
Outlet Diameter	76 MM

Additional Information

Country of Origin (Primary)	CN
Warranty Special	12 Months
UPC	06949521701963
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

REACH COOLING 42-10334 Cross Reference

We have 80 alternatives for the 42-10334 by REACH COOLING:

Fits Vehicles

Peterbilt 387 (2006-2007)
Peterbilt 377 (1989-2001)
Peterbilt 362 (1987-1989)
Peterbilt 359 (1987)
Peterbilt 385 (1996-2006)
Peterbilt 379 (1988-2007)
Peterbilt 378 (1988-2007)
Peterbilt 357 (1988, 1995-2007)

Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
