Name: Reach Cooling 61-1005 Charge Air Cooler
SKU: 611005
Price: 726.49 USD
Availability: InStock

REACH COOLING part description

Product Description

Charge Air Cooler

Application Summary

Freightliner:92 FLD112/89-94 FLD120

Features & Benefits

Flat Tube Wall Thickness: Flat tube wall thickness is no less than .55mm to maximize ability to withstand added pressure.
Header Plate Bond: We use a wider angle header plate bond to eliminate the risk of header cracking.
Reach charge air coolers are built to withstand the pressures of long hauls. From the product design to the package it is shipped in, every consideration is taken to ensure longevity and peak performance.
Reinforced Aluminum Alloy: Header reinforced with aluminum bronze to increase strength by 50%.
Reinforcement Rib: Tubes feature a reinforcing rib to increase material strength.
7 Layer Packaging: Each charge air cooler is packaged in a heavy duty, 7 layer corrugated box to ensure best protection during transit.
Deep Extrusion Header: Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion.

Product Attributes

Core Thickness	2 3/4 IN
Core Length	21 3/8 IN
Inlet Header Length	21.125 in
Inlet Outside Diameter	4 1/16 IN
Outlet Location	Upper Right
Outlet Outside Diameter	4.062 IN
Outlet Header Length	536 mm
Outlet Header Width	79 mm
Inlet Header Width	79 mm
Core Height	30 11/16 IN
Core Row Quantity	1
Inlet Location	Upper Left
Inlet Header Length	536 mm
Outlet Header Length	21 1/8 in
Outlet Header Width	3 1/8 in
Inlet Header Width	3 1/8 in
Core Height	779.5 MM
Inlet Outside Diameter	103.2 MM
Outlet Outside Diameter	103 MM
Core Length	542.9 MM
Type	Harmonica-shaped tube
Core Thickness	69.9 MM

Additional Information

Country of Origin (Primary)	CN
UPC	06949521755966

Part Interchanges

REACH COOLING 61-1005 Cross Reference

We have 163 alternatives for the 61-1005 by REACH COOLING:

Fits Vehicles

Freightliner FLD120 (1989, 1991, 1994)
Freightliner FLD112 (1992)
