Name: Reach Cooling 42-10433 HINO 238-258-268-338 02-13
SKU: 4210433
Price: 576.99 USD
Availability: InStock

REACH COOLING part description

HINO 238/258/268/338 02-13

Make	Hino
Model	238,258,268,338
Year	2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013

Product Description

HINO 238-258-268-338 02-13

Application Summary

HINO 238-258-268-338 02-13

Features & Benefits

Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Our fin edges are folded for increased stability and heat disbursement properties.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Folded fin edges increase stability and heat disbursement properties.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Core Thickness	1 9/16 IN
Core Width	24.75 IN
Core Height	27.5 IN
Inlet Diameter	2 3/16 IN
Transmission Oil Cooler Distance between Fittings	14-3/4 IN
Outlet Diameter	2 3/16 IN
Core Width	628.65 MM
Core Width	628.8 MM
Core Thickness	39.674 MM
Core Thickness	39.7 MM
Frame Included	No
Outlet Diameter	55.549 MM
Core Material	Aluminum
Down Flow Or Cross Flow Type	Down Flow
Outlet Location	Bottom Left
Tank Material	PA66-GF30
Inlet Diameter	55.549 mm
Inlet Diameter	55.6 MM
Engine Oil Cooler Included	No
Outlet Diameter	55.6 MM
Core Height	698.5 MM
Core Height	698 MM
Transmission Oil Cooler Included	No
Inlet Location	Top Right
Radiator Cap Included	No

Additional Information

Country of Origin (Primary)	CN
Warranty Special	12 Months
UPC	06941099904531
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

REACH COOLING 42-10433 Cross Reference

We have 41 alternatives for the 42-10433 by REACH COOLING:

Fits Vehicles

Hino 338CT (2008-2013)
Hino 268A (2008-2013)
Hino 258LP (2006-2013)
Hino 268 (2005-2013)
Hino 338 (2005-2013)
Hino 238 (2005-2013)
