Name: Reach Cooling 42-10472 2010 and Newer - 4900EX w- Detroit Diesel DD15
SKU: 4210472
Price: 847.99 USD
Availability: InStock

REACH COOLING part description

2010 and Newer - 4900EX w/ Detroit Diesel DD15 reference 42-10476 w/toc Compare

Make	Western Star
Model	4900EX, Detroit Diesel DD15

Product Description

2010 and Newer - 4900EX w- Detroit Diesel DD15

Application Summary

2010 and Newer - 4900EX w- Detroit Diesel DD15

Features & Benefits

Folded fin edges increase stability and heat disbursement properties.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Our fin edges are folded for increased stability and heat disbursement properties.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Core Thickness	2 3/16 IN
Down Flow Or Cross Flow Type	Down Flow
Outlet Diameter	2 9/16 IN
Core Height	39 IN
Core Width	40 5/8 IN
Inlet Diameter	2.5 IN
Fitting Connection Type	Pipe connect
Inlet Diameter	63.5 mm
Inlet Location	Upper Right
Radiator Cap Included	No
Core Height	990.6 MM
Outlet Diameter	65.074 MM
Transmission Oil Cooler Included	No
Core Height	991 MM
Engine Oil Cooler Included	No
Inlet Diameter	64 MM
Core Width	1031.875 MM
Core Width	1031.9 MM
Outlet Diameter	63.5 MM
Core Thickness	55.549 MM
Frame Included	No
Core Thickness	55.6 MM
Outlet Location	Lower Right

Additional Information

Warranty Special	12 Months
Country of Origin (Primary)	CN
UPC	06941099903497
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

REACH COOLING 42-10472 Cross Reference

We have 25 alternatives for the 42-10472 by REACH COOLING:

Fits Vehicles

Western Star 4900EX (2010-2015)

Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
