Name: Reach Cooling 42-10207 Radiator
SKU: 4210207
Price: 626.49 USD
Availability: InStock

REACH COOLING part description

2003-2008 Volvo VN Series

Specifications

Height	35 7/16 (Inches)
Width	34 15/16"
Thickness	1 7/8 (Inches)
Row	2
Inlet	2 1/2 (Inches)
Outlet	2 1/2 (Inches)
Core Material	Aluminum
Tank Material	Plastic
EOC	NONE (Inches)

Make	Volvo, Mack
Model	VN, VNL
Year	2003, 2004, 2005, 2006, 2007

Product Description

Radiator

Application Summary

03-08 Volvo VNL; 04-09 Volvo VNM; 05-07 Mack CXN; 06-07 Mack CHN

Features & Benefits

Our fin edges are folded for increased stability and heat disbursement properties.
Folded fin edges increase stability and heat disbursement properties.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Transmission Oil Cooler Type	10 In. Fan Side
Core Thickness	1.875 IN
Tank Material	Plastic
Inlet Diameter	2 1/2 IN
Core Width	34.937 IN
Core Row Quantity	2
Core Height	35 7/16 IN
Outlet Diameter	2 1/2 IN
Down Flow Or Cross Flow Type	Down Flow
Core Material	Aluminum
Transmission Oil Cooler Distance between Fittings	10 IN
Frame Included	No
Core Height	900.1 MM
Inlet Header Length	911.2 MM
Inlet Header Width	3.187 IN
Outlet Header Width	3 3/16 IN
Engine Oil Cooler Included	No
Outlet Header Length	35 7/8 IN
Core Thickness	47.625 MM
Outlet Location	Lower Right
Radiator Cap Included	No
Outlet Diameter	63.5 MM
Core Width	888 MM
Inlet Header Width	81 MM
Inlet Diameter	63.5 MM
Core Height	900.099 MM
Inlet Header Length	35.875 IN
Inlet Header Length	911.225 mm
Outlet Header Width	80.949 mm
Outlet Header Width	81 MM
Outlet Diameter	63.5 MM
Inlet Diameter	63.5 mm
Inlet Location	Upper Right
Core Width	887.399 MM
Outlet Header Length	911.225 mm
Core Thickness	48 MM
Outlet Header Length	911.2 MM
Transmission Oil Cooler Included	Yes
Transmission Oil Cooler Distance between Fittings	254 MM
Inlet Header Width	80.949 mm
Transmission Oil Cooler Distance between Fittings	254 MM

Additional Information

Warranty Special	12 Months
Country of Origin (Primary)	CN
UPC	06949521784652
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

REACH COOLING 42-10207 Cross Reference

We have 285 alternatives for the 42-10207 by REACH COOLING:

Fits Vehicles

Volvo VNM (2004-2009)
Volvo VNL (2003-2008)
Mack CXN (2005-2007)
Mack CHN (2004-2007)

Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
