MONROE part description

Product Description

OESpectrum Suspension Shock Absorber

Features & Benefits

  • EXCEPTIONAL HANDLING -- Full displaced valving adjusts to road extremes to provide a smooth ride while free floating dividing piston separates fluid from high-pressure gas charging for reduced shock fade and aeration
  • IMPROVES PERFORMANCE -- High pressure nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration and tight damping response provides vehicle control
  • CONSISTENT RIDE -- High-temperature OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • MAINTAINS STABILITY -- Monotube technology maintains vehicle control over bumps, dips and potholes for vehicles originally equipped with monotube shocks and struts
  • CONTROL AND DURABILITY -- PTFE-banded piston provides consistent sealing between piston and high-strength pressure tube for better control, increased durability and longer service life
  • BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
  • BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
  • BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee

Product Attributes

9791 CLEV
9789 S1
Dust Shield Included No
9783 No
9908 No
9792 No
Part Description Shock Absorber
Compressed Length 15.31 IN
Extended Length 21.86 in
Gas Charged Yes
Lower Mount Type Clevis Bracket Mount
Parts Pack(s) P01718,P00590
Travel Length 6.55 in
Upper Mount Type Stem Mount - Stem Length X M10 Thread Pitch
Compressed Length 388.9 MM
Extended Length 555.2 MM
Travel Length 166.4 MM
Lower Mount Type Clevis Bracket Mount
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Center of Mounting Hole

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) CA
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598134189
VMRS Code 016008003
UNSPSC 25172011

Part Interchanges

MONROE 39114 Cross Reference

We have 7 alternatives for the 39114 by MONROE:

Fits Vehicles

  • Cadillac CTS (2003-2014)
