65409 by MONROE - SHOCK
MONROE
Tap to view 5 more

MSRP: $154.55

$73.99

Save $80.56

Limited availability at this price!

In Stock

Get it by Friday, Jan 2
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 65409 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65409 Specifications

Product Attributes

Lower Mount Code LS53
Upper Mount Code LS53
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout Yes
Part Description Shock Absorber
Internal Construction Type Twin Tube
Adjustable Damping No
Color Black
Finish Painted
Shock Absorber Bore Size 1-3/4 IN
Foam Cell Design No
Shaft Diameter 18 MM
Compressed Length 15.75 IN
Dust Shield Material Metal
Extended Length 24.75 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 2" Sleeve OAL
Parts Pack(s) None
Travel Length 9 in
Upper Mount Type Loop Bushing and Sleeve Mount - 5/8" Sleeve ID X 2" Sleeve OAL
Compressed Length 400 MM
Extended Length 628.7 MM
Travel Length 228.6 MM
Shock Absorber Rod End Measuring Point Center of Loop
Shock Absorber Body End Measuring Point Center of Loop
Shock Absorber Bore Size 44.5 MM
Shock Absorber Bore Size 1.75 IN
Adjustable Damping No

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598173096
VMRS Code 016008003
UNSPSC 25172011

MONROE 65409 Part Interchanges

Brand Part Number
International Harvester (IHC) 2018987C1
Monroe Vintage 601101, 66720, 70600, 651409, 6720
Nuturn/leland L57646
Neway 57374420, 57306720, 57365409
VOLVO / WHITE / GMC RCSA5003, SA5003, 3919594
Meritor M89411, M85003
Euclid E85003
International 3892445C1, 2018987C2, AMS650409, 600101, AMS600101
Gabriel 85003, 68018540Y, 68028140Y, 728603, 68024240Y, 68023840Y, 89411, 680185
KYB 341623
Mack 600101MT, 700418MT, 650409MT, 600101
OEM 1675455C1, 1590035C1, 501553C91, 2018987C1
Paccar Parts 680238
Koni 881562
Batco 1085003, 1085005
Chevrolet 3919594
Motorcraft CAX720
General Motors 3919594
MACK 600101MT, 650409MT, 700418MT
Monroe Shocks & Struts 601101, 651409, 66720, 6720, 70600
Dayton Parts M65409, 44185003
Navistar 1590035C1, 1675455C1, 2018987C1, 2018987C2, 3892445C1, 501553C91, 600101, AMS600101, AMS650409
Volvo GM Heavy Truck 3919594, RCSA5003, SA5003
NAPA Shocks 65409
Automann A85003, A89411
Gold Shock Absorber 9180152
Bulldog HD HD12150028
PRT HD 170139
FCS F347266

MONROE 65409 Fits Vehicles

  • International 9100i SBA (2000-2003)
  • International 9100 SBA (1998-1999)
  • International 9900ix (2000-2009)
  • International 9900i (2000-2018)
  • International F2654 (1980-1989)
  • International F2554 (1979-1989)
  • International 9800 SBA (1996-1999)
  • International 9400 (1990-1999)
  • International 8200 (1990-1998)
  • International 8100 (1990-2003)
  • International 9600 (1989-1996)
  • International 9700 (1989-1996)
  • International 9300 (1989-1999)
  • International 8300 (1989-1994)
  • International 2575 (1984-1989)
  • International F2575 (1979-1989)
  • International 2275 (1981-1989)
  • International F2275 (1979-1989)
  • International F2674 (1979-1989)
  • International F2574 (1979-1989)
  • International S1853 (1981-1989)
  • International S1823 (1980-1982)
  • International S1723 (1980-1985)
  • International 7100 (1990-1995)
  • International 4900 (1990-2003)
  • International 4800 (1990-2003)
  • International 4700 (1990-2003)
  • International 4600 (1990-1994)
  • International 3900FC (1991-1994, 1996)
  • International 2674 (1981-2003)
  • International 3800 (1987, 1990-2004)
  • International 3700 (1990-1994)
  • International 2574 (1984-2003)
  • International 2654 (1999-2000)
  • International 2554 (1981-2002)
  • International 1652SC (1986-1992)
  • International 1452SC (1987-1992)
  • IC Corporation RE School Bus (2003-2016)
