MONROE MA719 Part Description
Manufacturer
Product Description
Max-Air Air Adjustable Air Shock Absorber Pack of 2
Features & Benefits
- MAINTAIN RIDE HEIGHT UNDER LOAD -- Air chamber can be inflated or deflated up to 150 PSI to maintain level height with additional weight up to 1,200 lbs. (capacity is limited by suspension, tires and transmission; see owner's manual)
- EASY TO ADJUST -- Special air fitting resists air leakage and ties into factory system (where applicable) or manually inflates with an air compressor; pair with Monroe air shock accessory and shock air hose AK kits (varies by application)
- EXCEPTIONAL HANDLING -- Full-displaced valving on compression and extension cycles for a smooth ride
- BUILT TO LAST -- Hardened and precision ground piston rod for consistent performance, sintered iron piston for enhanced durability and longer service life and lubricated air sleeve reduces friction for smooth operation
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
MONROE MA719 Specifications
Product Attributes
| Compressed Length | 14.5 IN |
| Extended Length | 23.75 in |
| Travel Length | 9.25 in |
| Lower Mount Code | L1/CP3 |
| Lower Mount Type | L1/CP3 |
| Upper Mount Code | XP7 |
| Upper Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/8" Pin Length (Hole Center to Center) |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Includes Bump Stop | Yes |
| Hydraulic Lockout | No |
| Parts Pack(s) | (2) P00576 |
| Part Description | Air Shock Absorber |
| Internal Rebound Bumper | No |
| Compressed Length | 368.3 MM |
| Extended Length | 603.3 MM |
| Travel Length | 235 MM |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Shock Absorber Rod End Measuring Point | Center of Cross Pin |
| Lower Mount Type | Loop Bushing and Cantilever Pin Mount - 1/2" Stud Diameter X 1 5/16" Stud Length (Center of Loop to Frame) |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598030825 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE MA719 Cross References
| Brand | Part Number |
|---|---|
| MA719MM, JB5Z7851728AA | |
| GABRIEL | 49128 |
| NAPA Shocks | MA719 |
MONROE MA719 Fits Vehicles
- Pontiac Executive (1967-1970)
- Pontiac Star Chief (1965-1966)
- Pontiac Grand Prix (1965-1968)
- Pontiac Catalina (1965-1970)
- Pontiac Bonneville (1965-1970)
- Oldsmobile Starfire (1965-1966)
- Oldsmobile Jetstar 88 (1965-1966)
- Oldsmobile Delmont 88 (1967-1968)
- Oldsmobile Delta 88 (1965-1970)
- Oldsmobile 98 (1965-1970)
- Chevrolet Impala (1965-1970)
- Buick Wildcat (1965-1970)
- Buick Estate Wagon (1970)
- Buick LeSabre (1965-1970)
- Buick Electra (1965-1970)
- Cadillac Fleetwood (1971-1976)
- Cadillac DeVille (1971-1976)
- Cadillac Calais (1971-1976)
