(888) 312-8812 Login SignupMONROE 911268 Reflex Suspension Shock Absorber
Tap to view 5 more
SHIPS TODAY
MSRP: $119.57
$6699
Save $52.58
Limited availability at this price!
In Stock
Get it by Monday, Jan 5
MONROE 911268 Part Description
Manufacturer
Product Description
Reflex Suspension Shock Absorber
Features & Benefits
- IMPROVES STABILITY -- ASD (Acceleration Sensitive Damping) valving technology adjusts to impacts, reducing roll and dive for vehicles with a higher center of gravity
- EXCEPTIONAL HANDLING -- Full displaced valving, tuned specifically to each vehicle, adjusts to road extremes while the larger bore provides more efficient damping control to provide consistency and a smooth ride
- CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger reserve tube holds more fluid to run cooler
- CONTROL AND DURABILITY -- Fluon-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
- IMPROVES PERFORMANCE -- Nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration
- BUILT TO LAST -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
MONROE 911268 Specifications
Product Attributes
| Lower Mount Code | LS26 |
| Upper Mount Code | L1 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | No |
| Part Description | Shock Absorber |
| Compressed Length | 18.5 IN |
| Dust Shield Material | Metal |
| Extended Length | 31.375 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 12MM Sleeve ID X 1.1/2" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 12.875 in |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Compressed Length | 469.9 MM |
| Extended Length | 796.9 MM |
| Travel Length | 327 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598841957 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 911268 Part Interchanges
| Brand | Part Number |
|---|---|
| Ford | 1C3Z18125LA, 5C3Z18124AA, 5C3Z18124BA, 5C3Z18124CA, 5C3Z18124FA, 5C3Z18124KA, 5C3Z18124LA, 5C3Z18124MA, 5C3Z18124NA, 5C3Z18124NB, 5C3Z18124PA, 5C3Z18124RA, 5C3Z18124SA, 5C3Z18124TA, 5C3Z18124VA, 5C3Z18125CC, 5C3Z18125CF, 5C3Z18125CH, 5C3Z18125CJ, 5C3Z18125D, 5C3Z18125E, 5C3Z18125F, 5C3Z18125G, 5C3Z18125LA, 5C3Z18125LB, 5C3Z18125LC, 5C3Z18125LD, 5C3Z18125LE, 5C3Z18125LF, 5C3Z18125MF, 6C3Z18124AGA, 6C3Z18124PBA, 6C3Z18124PHA, 6C3Z18125A, 6C3Z18125B, 6C3Z18125CEA, 6C3Z18125MBG, 6C3Z18125MHA, 7C3Z18124AE, 7C3Z18124AF, 7C3Z18124AGA, 7C3Z18124AH, 7C3Z18124AKA, 7C3Z18124APA, 7C3Z18124ARA, 7C3Z18124EA, 7C3Z18124NBA, 7C3Z18124NCA, 7C3Z18124NDA, 7C3Z18124NEA, 7C3Z18124NGA, 7C3Z18124P, 7C3Z18124PBA, 7C3Z18124PCA, 7C3Z18124PDA, 7C3Z18124PGA, 7C3Z18125CCA, 7C3Z18125CEA, 7C3Z18125CLA, 7C3Z18125CUA, 7C3Z18125CVA, 7C3Z18125CXA, 7C3Z18125LBA, 7C3Z18125LCA, 7C3Z18125LDA, 7C3Z18125LEA, 7C3Z18125LGA, 7C3Z18125M, 7C3Z18125MBA, 7C3Z18125MCA, 7C3Z18125MDA, 7C3Z18125MGA, 8C3Z18124NK, 8C3Z18124PK, 8C3Z18125LK, 8C3Z18125MK, 9C3Z18124A, 9C3Z18124B, 9C3Z18124PDA, 9C3Z18125A, 9C3Z18125B, BC3418080LEC, BC3Z18124A, BC3Z18124AA, BC3Z18124AB, BC3Z18124B, BC3Z18124C, BC3Z18124D, BC3Z18124E, BC3Z18124F, BC3Z18124G, BC3Z18124H, BC3Z18124K, BC3Z18124M, BC3Z18124N, BC3Z18124P, BC3Z18124Q, BC3Z18124R, BC3Z18124T, BC3Z18124U, BC3Z18124V, BC3Z18124W, BC3Z18124X, BC3Z18124Y, BC3Z18124Z, BC3Z18125A, BC3Z18125AA, BC3Z18125AB, BC3Z18125AC, BC3Z18125AG, BC3Z18125AH, BC3Z18125AK, BC3Z18125AM, BC3Z18125AN, BC3Z18125B, BC3Z18125C, BC3Z18125D, BC3Z18125E, BC3Z18125F, BC3Z18125J, BC3Z18125K, BC3Z18125N, BC3Z18125P, BC3Z18125S, BC3Z18125T, BC3Z18125U, BC3Z18125V, BC3Z18125W, BC3Z18125Y, BC3Z18125Z, F81Z18124AK, F81Z18124AL, F8AZ18125JA |
| FCS Auto Parts | 342509 |
| OEM | BC3Z18125AK, BC3Z18125K, BC3Z18125W, BC3Z18125U, BC3Z18125AM, 7C3Z18125MDA, 7C3Z18125MBA, 7C3Z18125MCA, BC3Z18125Z, BC3Z18125J, BC3Z18125P, 7C3Z18125LGA, 7C3Z18125MGA, 7C3Z18125LEA, BC3Z18125AG, 9C3Z18125A, BC3418080LEC, 7C3Z18125LCA, 7C3Z18125LDA, BC3Z18125S, BC3Z18125T, 9C3Z18125B, 8C3Z18125LK, BC3Z18125Y, BC3Z18125N, 8C3Z18125MK, 7C3Z18125LBA, BC3Z18125V |
| Motorcraft | ASH1011, ASH1012, ASH1013 |
| Sachs | 30878 |
| KYB | KG54333, 554388, 565124, 554363, 345072, 565123, 555056, 554366, 565091, 345070, 344419 |
| Gabriel | 61682, G63888, G63964 |
| Rancho | RS5047, RS55047 |
| NAPA Shocks | 911268, NS911268 |
| FCS | 342509 |
| Duralast | TS3332612B |
| MasterPro Shocks and Struts | FD110 |
MONROE 911268 Fits Vehicles
- Ford F-350 Super Duty (2005-2016)
MONROE 911268 Cross References
We have 41 alternatives for the 911268 by MONROE:
- 911268MM
- MERITOR MG61888
- POWER10 PARTS SSA-G63888
- GABRIEL G63888
- FCS AUTO PARTS 342509
- OEM BC3Z18125AK
- OEM BC3Z18125K
- OEM BC3Z18125W
- OEM BC3Z18125U
- OEM BC3Z18125AM
- OEM 7C3Z18125MDA
- MOTORCRAFT ASH1011
- OEM 7C3Z18125MCA
- OEM 7C3Z18125MBA
- SACHS NORTH AMERICA 30878
- OEM BC3Z18125Z
- MOTORCRAFT ASH1012
- MOTORCRAFT ASH1013
- KYB KG54333
- OEM BC3Z18125J
- OEM BC3Z18125P
- OEM 7C3Z18125LGA
- OEM 7C3Z18125MGA
- OEM 7C3Z18125LEA
- OEM 9C3Z18125A
- OEM BC3Z18125AG
- GABRIEL 61682
- OEM BC3418080LEC
- OEM 7C3Z18125LCA
- KYB 554388
- OEM 7C3Z18125LDA
- OEM BC3Z18125S
- OEM BC3Z18125T
- OEM 9C3Z18125B
- OEM 8C3Z18125LK
- OEM BC3Z18125Y
- OEM BC3Z18125N
- GABRIEL G63964
- OEM 8C3Z18125MK
- OEM 7C3Z18125LBA
- OEM BC3Z18125V
