Monroe 66863 - Magnum Suspension Shock Absorber
$5099
MSRP: $64.19
Save: $13.20
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
MONROE part description
Product Description
Magnum Suspension Shock Absorber
Features & Benefits
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
- BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
Product Attributes
9791 | L3 |
9789 | L3 |
Dust Shield Included | Yes |
9783 | No |
9908 | No |
9792 | No |
Part Description | Shock Absorber |
Compressed Length | 18 IN |
Dust Shield Material | Metal |
Extended Length | 30.75 in |
Gas Charged | Yes |
Lower Mount Type | Loop Bushing Mount - 3/4" Bushing ID X 1.9/16" Bushing OAL |
Parts Pack(s) | P00119 |
Travel Length | 12.75 in |
Upper Mount Type | Loop Bushing Mount - 3/4" Bushing ID X 1.9/16" Bushing OAL |
Compressed Length | 457.2 MM |
Extended Length | 781.1 MM |
Travel Length | 323.8 MM |
Shock Absorber Rod End Measuring Point | Center of Loop |
Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
MSDS Sheet Number | 1164 |
Country of Origin (Primary) | US |
Canadian Harmonizing Tariff Code | 8708803000 |
Harmonized Tariff Code (Schedule B) | 8708801600 |
Harmonized Tariff Code (HTS) | 8708801600 |
UPC | 00048598074119 |
VMRS Code | 016008003 |
UNSPSC | 25172011 |
Part Interchanges
- General Motors 359010017
- Gabriel 59017
- Ford F4HZ18124A
- Ford F5HZ18124A
- Ford D7HT18045CA
- VOLVO / WHITE / GMC 359010017
- Ford D2HT18045CA
- Ford D0HA18045C
- Nuturn/leland L59017
- Ford C4HZ18124C
- Ford D0HZ18124C
- Ford C6PF18077DN
- Ford D2TZ18124G
- Ford F4HT18045AB
- International 873619C92
- Ford DOHZ18124C
- Ford D2HF18124AA
- Mack 660119MT
- Gabriel 727641
- Ford D7HT18124CA
- Monroe Vintage 601119
- KYB 345615
- Motorcraft CAX863
- Mack 600119
- Neway 57366863
- International AMS660119
- Mack 600119MT
- International 873619C93
- Ford E8HT18045HA
- Gabriel 83314
- Meritor M83314
- Monroe Vintage 6863
- Ford C1TZ18124N
- Ford C1TT18045E
- International 873619C3
- Euclid E83314
- Ford D2HF18045AA
- International AMS600119
- Chevrolet 359010017
- Sachs 317939
- Ford D2HF18045A
- Monroe Vintage 6809
- Monroe Vintage 70314
- Neway 57306863
- MACK 600119
- MACK 600119MT
- MACK 660119MT
- Monroe Shocks & Struts 601119
- Monroe Shocks & Struts 6809
- Monroe Shocks & Struts 6863
- Monroe Shocks & Struts 70314
- Navistar 873619C3
- Navistar 873619C92
- Navistar 873619C93
- Navistar AMS600119
- Navistar AMS660119
- Volvo GM Heavy Truck 359010017
- NAPA Shocks 66863
- Gold Shock Absorber 5001278
- Gold Shock Absorber 9180251
- KYB 345614
- KYB 341624
MONROE 66863 Cross Reference
We have 48 alternatives for the 66863 by MONROE:
- MERITOR M83314
- 66863MM
- MAE66863
- GABRIEL 83314
- GM 359010017
- GABRIEL 59017
- FORD F4HZ18124A
- FORD F5HZ18124A
- FORD D7HT18045CA
- VOLVO / WHITE / GMC 359010017
- FORD D2HT18045CA
- FORD D0HA18045C
- NUTURN/LELAND L59017
- FORD C4HZ18124C
- FORD D0HZ18124C
- FORD C6PF18077DN
- FORD D2TZ18124G
- FORD F4HT18045AB
- INTERNATIONAL 873619C92
- FORD DOHZ18124C
- FORD D2HF18124AA
- MACK 660119MT
- GABRIEL 727641
- FORD D7HT18124CA
- MONROE VINTAGE 601119
- KYB 345615
- MOTORCRAFT CAX863
- MACK 600119
- NEWAY 57366863
- INTERNATIONAL AMS660119
- MACK 600119MT
- INTERNATIONAL 873619C93
- FORD E8HT18045HA
- MONROE VINTAGE 6863
- FORD C1TZ18124N
- FORD C1TT18045E
- INTERNATIONAL 873619C3
- EUCLID E83314
- FORD D2HF18045AA
- INTERNATIONAL AMS600119
- CHEVROLET 359010017
- SACHS NORTH AMERICA 317939
- FORD D2HF18045A
- MONROE VINTAGE 6809
- MONROE VINTAGE 70314
- NEWAY 57306863
- HALDEX SA66863
- BULLDOG HD SHOCKS HD1214-0550
Fits Vehicles
- Ford LT800 (1981-1984)
- Ford LNT800 (1981)
- Ford LN900 (1981)
- Ford LNT900 (1981)
- Ford L900 (1981)
- Ford LNT8000 (1981)
- Ford LTS8000 (1981-1985)
- Ford LT8000 (1981-1985)
- Ford LNT9000 (1981)
- Ford LTL9000 (1982-1985)
- Ford LN9000 (1981)
- Ford LT9000 (1981-1985)
- Ford LTS9000 (1981-1985)
- Ford L9000 (1981-1985)
- Ford L8000 (1981-1985)
- Ford LN8000 (1981)
- Ford LN800 (1980-1981)
- Ford L800 (1980-1985)
- Ford FT800 (1980-1990)
- Ford F-800 (1983-1990)
- Ford F-700 (1983-1990)
- Ford F-600 (1983-1990)
