MONROE 66608 Part Description
Manufacturer
Features & Benefits
- Compression cycle full-displaced valving offers controlled ride and handling for hardworking trucks and vans
- Heavy-duty construction, featuring nitrocarburized rod and sintered iron piston, enhances durability significantly
- Increased oil capacity helps to ensure the shock absorber works efficiently and lasts longer
- Nitrogen gas charge minimizes aeration, improving ride stability and maintaining consistent tire contact
- Smooth rod reaction guaranteed by OE all-weather fluid, resistant to extreme temperature variations
Monroe Gas-Magnum 60 Series Suspension Shock Absorber
Achieve optimal ride control and comfort with the Monroe Gas-Magnum 60 Series Suspension Shock Absorber. Ideal for midsize and full-size trucks and vans, this Monroe 66608 shock absorber is designed to deliver firm control without the uncomfortable jolt. It features a heavy-duty nitrocarburized rod and a sintered iron piston, both contributing to its remarkable durability and longer service life. The larger bore, along with the 2-inch reserve tube, allows for more oil capacity, which enhances its efficiency. By maintaining tire-to-road contact through a nitrogen gas charge, it significantly improves ride quality and handling while reducing aeration and shock fade. Monroe’s OE all-weather fluid ensures peak performance in various climates, providing a consistently smooth driving experience.
MONROE 66608 Specifications
Product Attributes
| Lower Mount Code | LS54 |
| Upper Mount Code | LS54 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Part Description | Shock Absorber |
| Compressed Length | 11.6875 IN |
| Dust Shield Material | Metal |
| Extended Length | 16.8281 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 5.14 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Compressed Length | 296.9 MM |
| Extended Length | 427.4 MM |
| Travel Length | 130.6 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Active or Passive Suspension | Passive |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Extended Length (in) | 16.8281 |
| Extended Length (mm) | 427.4 |
| Adjustable Compression | No |
| Lower Mount Code | LS54 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Travel Length (mm) | 130.6 |
| Compressed Length (mm) | 296.9 |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Compressed Length (in) | 11.6875 |
| Upper Mount Code | LS54 |
| Mounting Hardware Included | No |
| Grade Type | Premium |
| Travel Length (in) | 5.14 |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598074638 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
