Name: Gabriel 89436 FleetLine Heavy Duty Shock Absorber
SKU: 89436
Price: 62.99 USD
Availability: InStock

GABRIEL part description

Product Description

FleetLine Heavy Duty Shock Absorber

Features & Benefits

Top of the line, adjustable, heavy-duty gas shock for class 7 – 8 vehicles, school buses and transit buses
Three settings for adjustability: OE ride (firm), increased handling & control (extra firm), or maximum driver comfort (regular)
Specially formulated high temp. fluid & multi-lip Viton rod seal reduces friction & wear, even in extreme operating conditions
Gas Cell design is superior to gas-charged shocks; gas cell double seals gas from fluid for optimum performance
Chromed piston rod to inhibit corrosion, ensure proper seal lubrication and provide a more consistent wear surface

GasSLXTM Shocks – Adjustable Commercial Truck and Trailer Shocks (89000 series) - The three position GasSLX™ adjustable shocks absorbers by Gabriel® allow you to choose from one of three settings – Firm, Regular and Extra Firm – to match different applications. The GasSLX shock incorporates a gas cell design, creating a physical barrier between gas and fluid, preventing aeration which can cause fade, or reduction in damping force. This gas cell technology is a full-life feature and is better suited for longer-life commercial vehicle applications. And like all Gabriel shocks and struts, GasSLX shocks feature a super-finished chrome piston rod for superior corrosion resistance and a leak-proof piston seal which extends product life. Advanced gas cell technology improves gas retention and provides more consistent high temperature operation. Unique pressurized piston seal design reduces force-velocity variabilities and self compensates for wear.

Product Attributes

Compression	217
External Diameter Illustration	G
Lower Mount Code	ES36
Recoil Cutoff	YES
Weight (lbs)	6.5
Bore	1-5/8"
Stroke (in)	5.2
Collapsed Length (in)	12.04
Installation Hardware Included	No
Rebound	998‡
Core Color	Y
Adjustable Damping	YES
Extended Length (in)	17.24
Dust Tube	YES
Upper Mount Code	ES36
HD Mounting Code Guide.pdf	https://gabriel.com/sites/default/files/2024_HD_Mounting_Code_Guide.pdf
Compression (lb)	217
Accessory Kit #	n/a
Package Contents	1 Shock
Rebound (lb)	998‡
Dust Tube Material	Steel

Additional Information

Harmonized Tariff Code (Schedule B)	8708801600
Country of Origin (Primary)	MX
MSDS Sheet Number	ARP002 / RC001
UPC	00043645924232
VMRS Code	016003016
UNSPSC	25172011
