(888) 312-8812 Login SignupMONROE 65549 Magnum Rear Suspension Shock Absorber
Tap to view 3 more
SHIPS TODAY
MSRP: $249.94
$10799
Save $141.95
Limited availability at this price!
In Stock
Get it by Tuesday, Jun 16
MONROE 65549 Part Description
Manufacturer
Product Description
Magnum Rear Suspension Shock Absorber
Features & Benefits
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
MONROE 65549 Specifications
Product Attributes
| Compressed Length | 14.55 IN |
| Compressed Length | 369.6 MM |
| Extended Length | 21.91 in |
| Extended Length | 556.5 MM |
| Travel Length | 7.92 in |
| Travel Length | 201.2 MM |
| Lower Mount Type | Loop (Eyelet) Bushing and Sleeve |
| Lower Mount Code | LS53 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 5/8"-16mm Sleeve ID X 3 9/16" Sleeve OAL |
| Upper Mount Code | LS87 |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| Gas Charged | Yes |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Body Diameter | 60.5 MM |
| Body Diameter | 2.38 IN |
| Body Color | Black |
| Cylinder Color | Black |
| Color | Black |
| Cylinder Finish | Painted |
| Dust Shield Included | Yes |
| Dust Shield Diameter | 69.1 MM |
| Dust Shield Diameter | 2.72 IN |
| Dust Shield Material | Metal |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Internal Rebound Spring | No |
| Hydraulic Lockout | Yes |
| Internal Construction Type | Twin Tube |
| Grade Type | Premium |
| Adjustable Damping | No |
| Active or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Part Description | Shock Absorber |
Additional Information
| MSDS Sheet Number | 01164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708800050 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598240026 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 65549 Cross References
MONROE 65549 Fits Vehicles
- International MV607 (2019-2026)
- International LT (2020-2024)
- International RH613 (2018-2024)
- International LoneStar (2017-2024)
- International LT625 (2017-2026)
- International ProStar (2017-2020)
- Nexus Ghost (2014-2024)
MONROE 65549 Customer Reviews
No reviews yet
Be the first to review this product!
MONROE 65549 Manufacturer Information
Monroe products are built for the road ahead. Since its founding in 1916, Monroe® has been known for its world-class solutions that are precision-engineered and meticulously tested with the specific vehicle's ride and handling profile in mind. As the leading supplier of Original Equipment ride control products to global automotive manufacturers, Monroe helped establish the benchmarks of handling and ride excellence in every stage of a vehicle's life. Whether you're upgrading your truck, converting its suspension, or restoring its original state, Monroe has got you covered. It offers the best-in-class shocks, strut assemblies, steering stabilizers, conversion kits, lift support, and many other suspension components that will help enhance your safety and driving experience.
MONROE 65549 Questions & Answers
No questions yet
Be the first to ask a question about this product!
