MONROE 66601 GAS-MAGNUM 60

$56.49

Limited availability at this price!

In Stock

Get it by Thursday, Jan 22
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed before 2pm EST will ship same day

MONROE 66601 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES   -- Designed to handle the demands of high mileage and severe use class 3-6 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while 2-in. or 2-1/4-in. reserve tube holds more fluid to improve performance (when required)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/8-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (on most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration, and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 66601 Specifications

Product Attributes

Lower Mount Code LS82
Upper Mount Code S4
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout No
Part Description Shock Absorber
Compressed Length 13.5 IN
Dust Shield Material Metal
Extended Length 22.875 in
Gas Charged Yes
Lower Mount Type Loop Bushing and Sleeve Mount - 5/8"-16MM Sleeve ID X 1.1/2" Sleeve OAL
Parts Pack(s) P01136
Travel Length 9.375 in
Upper Mount Type Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch
Compressed Length 342.9 MM
Extended Length 581 MM
Travel Length 238.1 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Center of Loop

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598074560
VMRS Code 016008003
UNSPSC 25172011

MONROE 66601 Cross References

BrandPart Number
66601MM, MAE66601
AutomannA83114
BULLDOG HD SHOCKSHD1213-0734
Bulldog HDHD12130734
CHEVROLET94057593, 8940575930, 94033786
GABRIEL83114
GM8940575930, 94033786, 94057593
GMC94057593
General Motors8940575930, 94033786, 94057593, 1516302191
HALDEXSA66601
INTERNATIONAL56101Z5008, AMS660160
ISUZU94033786
Isuzu1516302191
KYB345610, 345609, KG6198
MACK660160MT, 660160
MERITORM83114
MONROE VINTAGE76601, G67503, 660160, 661160, 34601
Monroe Shocks & Struts34601, 660160, 661160, 76601, G67503
NAPA Shocks66601
NAVISTARAMS66601
NEWAY57366601
NavistarAMS660160
OEM94057593, 1516302191, 56101Z5008
SACHS NORTH AMERICA317938
Sachs317938
UD56110Z5009, 56110Z5008

MONROE 66601 Fits Vehicles

  • International 400 (1991)
  • GMC W5500 Forward (1988)
  • Isuzu NPR (1988-1989)
  • Isuzu NRR (1988)
  • Isuzu FRR (1995-1998, 2000-2004)
  • Chevrolet W5500 Tiltmaster (1990-2003)
