MONROE 65436 Magnum Shock Absorber - 16.87 in. Extended Length, Front or Rear

65436 by MONROE - Magnum Shock Absorber - 16.87 in. Extended Length, Front or Rear
MONROE
Tap to view 5 more

$93.99

Limited availability at this price!

In Stock

Get it by Friday, Jan 23
No Hassle Return Policy Details
Free Economy shipping on orders over $499 details
Orders placed over the weekend will ship the following business day

MONROE 65436 Part Description

Manufacturer

MONROE

Product Description

Magnum Suspension Shock Absorber

Features & Benefits

  • FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
  • CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
  • EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
  • STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
  • BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
  • LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
  • REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
  • IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
  • BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
  • BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty

MONROE 65436 Specifications

Product Attributes

Lower Mount Code S6
Upper Mount Code S6
Dust Shield Included Yes
Includes Bump Stop No
Internal Rebound Bumper No
Hydraulic Lockout Yes
Part Description Shock Absorber
Compressed Length 11.375 IN
Dust Shield Material Metal
Extended Length 16.875 in
Gas Charged Yes
Lower Mount Type Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Parts Pack(s) (2) P01482
Travel Length 5.5 in
Upper Mount Type Stem Mount - 3.5/16" Stem Length X 5/8"-11 Thread Pitch
Compressed Length 288.9 MM
Extended Length 428.6 MM
Travel Length 139.7 MM
Shock Absorber Rod End Measuring Point Base of Stem
Shock Absorber Body End Measuring Point Base of Stem

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708803000
Harmonized Tariff Code (Schedule B) 8708801600
Harmonized Tariff Code (HTS) 8708801600
UPC 00048598173362
VMRS Code 016008003
UNSPSC 25172011

MONROE 65436 Cross References

BrandPart Number
65436MM, MAE65436
Alliance Truck PartsABPN32O900047, ABPN32G900047
BULLDOG HD SHOCKSHD1215-0077
Bulldog HDHD12150077
Dayton Parts44185900
FCSF343376, F347306, F343368, F344355, F344353, F344342, F347215, F344343, F347303, F343375
FREIGHTLINER1617144000, 1618103000, 1617361000, 16-17361-000
Freightliner1619391000
GABRIEL85900, 665903
Gold Shock Absorber8160118
HALDEXSA65436
INTERNATIONALAMS650436
KENWORTH665903, 70701
KYB441600, 341624
Kenworth665944
MACK650436MT
MERITORM85900
MONROE VINTAGE650436
Monroe Shocks & Struts650436
NAPA Shocks65436
NEWAY57365436
NavistarAMS650436
OEM70701, 1618103000, 665903, 665944
PACCAR PARTS665918
PETERBILT665944PLUS
POWER10 PARTSSSA-85900
SACHS NORTH AMERICA315553, 481700000477, 315402, 311633, 481700000493, 481700131919, 315404
Sachs315553, 481700000477, 315402, 311633, 481700000493, 481700131919, 315404
TORQUE PARTSTR85900
VOLVO / WHITE / GMCSA5900, RCSA5900
Volvo GM Heavy TruckRCSA5900, SA5900

MONROE 65436 Fits Vehicles

  • Kenworth C500 (2010-2016)
  • Kenworth K100E (1985-2003, 2005-2006)
  • Kenworth K100 (1981-1985)
  • Kenworth T400 (1982, 1984, 1989-1999)
  • Kenworth W900 (1981-2020)
  • Kenworth T800 (1987-2020)
  • Kenworth T600A (1986-2008)
  • Freightliner XC (2001-2005)
  • Kenworth T300 (1995-2008)
  • Kenworth K300 (1993-2005)
