Monroe 65104 - Magnum Suspension Shock Absorber
$7099
MSRP: $232.89
Save: $161.90
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
MONROE part description
Product Description
Magnum Suspension Shock Absorber
Features & Benefits
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360deg for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
- BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
Product Attributes
9791 | L4 |
9789 | L4 |
Dust Shield Included | Yes |
9783 | No |
9908 | No |
9792 | No |
Part Description | Shock Absorber |
Internal Construction Type | Twin Tube |
Adjustable Damping | No |
Color | Black |
Finish | Painted |
Shock Absorber Bore Size | 1-3/4 IN |
Foam Cell Design | No |
Shaft Diameter | 18 MM |
Compressed Length | 14 IN |
Dust Shield Material | Metal |
Extended Length | 21.875 in |
Gas Charged | Yes |
Lower Mount Type | Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL |
Parts Pack(s) | None |
Travel Length | 7.875 in |
Upper Mount Type | Loop Bushing Mount - 1" Bushing ID X 1.3/4" Bushing OAL |
Compressed Length | 355.6 MM |
Extended Length | 555.6 MM |
Travel Length | 200 MM |
Shock Absorber Rod End Measuring Point | Center of Loop |
Shock Absorber Body End Measuring Point | Center of Loop |
9801 | 44.5 MM |
9801 | 1.75 IN |
Adjustable Damping | No |
Additional Information
MSDS Sheet Number | 1164 |
Country of Origin (Primary) | US |
Canadian Harmonizing Tariff Code | 8708803000 |
Harmonized Tariff Code (Schedule B) | 8708801600 |
Harmonized Tariff Code (HTS) | 8708801600 |
UPC | 00048598170040 |
VMRS Code | 016008003 |
UNSPSC | 25172011 |
Part Interchanges
- Volvo 8065787
- Ford E8HS18080AA
- GABRIEL 85304
- General Motors 373010016
- International AMS650104
- Chevrolet 373010016
- OEM 8065787
- Monroe Vintage 70119
- Mack 650104
- Kenworth 16454487
- Monroe Vintage 650104
- Neway 57365104
- Blue Bird 1553072
- Mack 650104MT
- Sachs 316814
- Gabriel 680370
- KENWORTH 16454487
- MACK 650104
- MACK 650104MT
- Haldex SA65104
- Gabriel 728639
- Gabriel 85026
- Meritor M85026
- Monroe Shocks & Struts 650104
- Monroe Shocks & Struts 70119
- Navistar AMS650104
- Volvo GM Heavy Truck 1093178
- Volvo GM Heavy Truck 8065787
- NAPA Shocks 65104
- Automann A85026
- FCS F344358
- KYB 341615
- KYB KG6007
- KYB 341633
- KYB KG6004
MONROE 65104 Cross Reference
We have 22 alternatives for the 65104 by MONROE:
- MERITOR M85304
- 65104MM
- MAE65104
- NAVISTAR AMS65104
- GABRIEL 85026
- FORD E8HS18080AA
- GABRIEL 85304
- GM 373010016
- INTERNATIONAL AMS650104
- CHEVROLET 373010016
- OEM 8065787
- MONROE VINTAGE 70119
- MACK 650104
- KENWORTH 16454487
- MONROE VINTAGE 650104
- NEWAY 57365104
- BLUE BIRD 1553072
- MACK 650104MT
- SACHS NORTH AMERICA 316814
- GABRIEL 680370
- HALDEX SA65104
- BULLDOG HD SHOCKS HD1215-0121
Fits Vehicles
- Ford F-800 (1988-1990)
- Ford F-700 (1988-1990)
- Ford F-600 (1988-1990)
