(888) 312-8812 Login SignupMONROE 58263 Load Adjusting Suspension Shock Absorber and Coil Spring Assembly Pack of 2
Tap to view 5 more
MSRP: $174.13
$10549
Save $68.64
Limited availability at this price!
In Stock
Get it by Tuesday, Jan 20
MONROE 58263 Part Description
Manufacturer
Product Description
Load Adjusting Suspension Shock Absorber and Coil Spring Assembly Pack of 2
Features & Benefits
- REDUCES SAG UNDER LOAD -- Ideal for occasionally hauling or towing varying loads; heavy gauge, calibrated coil spring reduces sag when loaded up to 1,200 lbs. (capacity limited by suspension, tires and transmission; see owner's manual)
- EXCEPTIONAL HANDLING -- Tuned specifically for each application, full-displaced valving automatically adjusts to road extremes to provide ride consistency
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and PTFE-banded piston helps reduce friction between the piston and pressure tube to enhance responsiveness to changing road surfaces
- LONGER SERVICE LIFE -- Self-lubricating fluid seal retains gas and reduces excessive friction against the piston rod to help reduce premature wear while heavy-duty nitrocarburized rod delivers long life
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
MONROE 58263 Specifications
Product Attributes
| Lower Mount Code | XP4 |
| Upper Mount Code | S4 |
| Includes Bump Stop | No |
| Hydraulic Lockout | No |
| Parts Pack(s) | P01134 |
| Part Description | Shock Absorber and Coil Spring Assembly |
| Compressed Length | 9.125 IN |
| Dust Shield Included | Yes |
| Dust Shield Material | Metal |
| Extended Length | 13.75 in |
| Internal Rebound Bumper | Yes |
| Lower Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/16" Pin Length (Hole Center to Center) |
| Travel Length | 4.625 IN |
| Upper Mount Type | Stem Mount - 2.3/8" Stem Length X 3/8"-16 Thread Pitch |
| Compressed Length | 231.8 MM |
| Extended Length | 349.3 MM |
| Travel Length | 4.625 in |
| Travel Length | 117.5 MM |
| Upper Mount Code | S4 |
| Dust Shield Included | Yes |
| Shock Absorber Rod End Measuring Point | Base of Stem |
| Shock Absorber Body End Measuring Point | Center of Mounting Hole |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598010681 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
MONROE 58263 Cross References
MONROE 58263 Fits Vehicles
- Ford Custom (1965-1972)
- Ford LTD Crown Victoria (1987-1991)
- Mercury Park Lane (1966-1968)
- Mercury Monterey (1965-1974)
- Mercury Marauder (1965-1970)
- Mercury Cyclone (1965-1967)
- Lincoln Mark III (1968-1971)
- Ford Galaxie 500 (1965-1974)
- Ford Galaxie (1965-1967)
- Chevrolet Biscayne (1965-1972)
- Pontiac Laurentian (1971-1974, 1976-1981)
- Mercury Montego (1972-1976)
- Mercury Marquis (1967-1982)
- Mercury Cougar (1974-1979)
- Mercury Grand Marquis (1975-1991)
- Mercury Colony Park (1965-1974, 1987-1991)
- Lincoln Town Car (1981-1991)
- Lincoln Mark VI (1980-1983)
- Lincoln Mark V (1977-1979)
- Lincoln Mark IV (1972-1976)
- Lincoln Continental (1970-1980)
- Ford Torino (1972-1976)
- Ford Thunderbird (1967-1979)
- Ford Ranchero (1972-1979)
- Ford LTD II (1977-1979)
- Ford Gran Torino (1972-1976)
- Ford Custom 500 (1965-1977)
- Ford LTD (1967-1986)
- Ford Country Squire (1987-1991)
- Pontiac Safari (1987-1989)
- Pontiac Parisienne (1971-1974, 1976-1986)
- Pontiac Grand Safari (1971-1978)
- Pontiac Grandville (1971-1975)
- Pontiac Firebird (1970-1981)
- Pontiac Catalina (1971-1981)
- Pontiac Bonneville (1971-1981)
- Oldsmobile Delta 88 (1971-1985)
- Oldsmobile Custom Cruiser (1971-1992)
- Oldsmobile 98 (1971-1984)
- Chevrolet Impala (1965-1985)
- Chevrolet Caprice (1966-1996)
- Chevrolet Camaro (1970-1981)
- Chevrolet Bel Air (1965-1975, 1981)
- Cadillac Brougham (1987-1992)
- Cadillac Fleetwood (1977-1986, 1993-1996)
- Cadillac DeVille (1977-1984)
- Cadillac Commercial Chassis (1977-1996)
- Buick Roadmaster (1991-1996)
- Buick Riviera (1971-1978)
- Buick LeSabre (1971-1990)
- Buick Estate Wagon (1971-1983)
- Buick Electra (1971-1989)
