Monroe 34802 - Gas-Magnum Suspension Shock Absorber
$3649
MSRP: $63.50
Save: $27.01
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
MONROE part description
Product Description
Gas-Magnum Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
Product Attributes
| 9791 | L1 |
| 9789 | L1 |
| Dust Shield Included | Yes |
| 9783 | No |
| 9908 | No |
| 9792 | No |
| Part Description | Shock Absorber |
| Compressed Length | 14 IN |
| Dust Shield Material | Metal |
| Extended Length | 22.75 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Parts Pack(s) | P00829 |
| Travel Length | 8.75 in |
| Upper Mount Type | Loop Bushing Mount - 5/8" Bushing ID X 1.5/16" Bushing OAL |
| Compressed Length | 355.6 MM |
| Extended Length | 577.9 MM |
| Travel Length | 222.3 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598049001 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
Part Interchanges
- Toyota 4851169036
- Toyota 4851169066
- Toyota 4853160020
- Toyota 4853160081
- Toyota 4853160160
- Toyota 4853169047
- Hino 485302510
- KYB KG4026
- FCS Auto Parts 342487
- Monroe Vintage 4065
- Hino 485301910
- OEM 485302510
- Haldex SA34802
- Gabriel 727616
- Meritor M83216
- Monroe Shocks & Struts 4065
- Fleetrite AMS85802
- NAPA Shocks 76802
- Automann A83216
- Gold Shock Absorber 9150063
- FCS 342487
- KYB KG5466
- KYB KG5438
- FCS 342478
- KYB 344090
- KYB 344015
MONROE 34802 Cross Reference
We have 9 alternatives for the 34802 by MONROE:
Fits Vehicles
- Hino FB1715 (1993-1997)
- Hino FB15 (1992)
- Hino FA1415 (1993-1997)
- Hino FB14 (1989-1991)
- Hino FA14 (1989-1991)
- Hino FB1817 (1998-2004)
- Hino FA1517 (1998-2004)
- Ford Econoline (1961-1967)
- Toyota Land Cruiser (1971-1987)
