(888) 312-8812 Login SignupMagnum Suspension Shock Absorber
| Lower Mount Code | LS54 |
| Upper Mount Code | LS54 |
| Dust Shield Included | Yes |
| Includes Bump Stop | No |
| Internal Rebound Bumper | No |
| Hydraulic Lockout | Yes |
| Part Description | Shock Absorber |
| Compressed Length | 12.08 IN |
| Dust Shield Material | Metal |
| Extended Length | 17.18 in |
| Gas Charged | Yes |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Parts Pack(s) | None |
| Travel Length | 5.1 in |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Compressed Length | 306.8 MM |
| Extended Length | 436.4 MM |
| Travel Length | 129.5 MM |
| Shock Absorber Rod End Measuring Point | Center of Loop |
| Shock Absorber Body End Measuring Point | Center of Loop |
| MSDS Sheet Number | 1164 |
| Country of Origin (Primary) | US |
| Canadian Harmonizing Tariff Code | 8708803000 |
| Harmonized Tariff Code (Schedule B) | 8708801600 |
| Harmonized Tariff Code (HTS) | 8708801600 |
| UPC | 00048598173935 |
| VMRS Code | 016008003 |
| UNSPSC | 25172011 |
| Brand | Part Number |
|---|---|
| Hendrickson | S21699, A21699 |
| Meritor | M85934, 680714 |
| OEM | 1270563B003, S21699 |
| Gabriel | 695348, 85934, 87018 |
| Monroe Vintage | 11494, OE11494 |
| Haldex | SA65493 |
| Monroe Shocks & Struts | 11494, OE11494 |
| Arvin | 695348 |
| Ridewell Corp | 1270563B003 |
| NAPA Shocks | 65493 |
| Gold Shock Absorber | 9180200 |
| Bulldog HD | HD12150047 |
| Cush Suspensions | OE11494 |
| Dayton Parts | 44185934 |
Be the first to review this product!
