Monroe 34532 - Gas-Magnum Suspension Shock Absorber
$4849
MSRP: $105.40
Save: $56.91
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
MONROE part description
Product Description
Gas-Magnum Suspension Shock Absorber
Features & Benefits
- DESIGNED FOR TRUCKS AND VANS -- Engineered for hardworking full-size trucks and vans and features full-displaced valving on compression cycles to deliver controlled ride and handling
- BUILT TO LAST -- Heavy-duty nitrocarburized rod (non-dust shield units only) and sintered iron piston enhance durability for longer service life while self-lubricating fluid seal reduces friction against piston rod to reduce wear
- CONSISTENT RIDE -- OE all-weather fluid contains special modifiers to handle extreme temperatures and help reduce friction and ensure smooth rod reaction
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- LONGER SERVICE LIFE -- Larger bore and bigger 2-in. reserve tube work together to hold more oil for greater capacity to allow the shock to work efficiently for controlled ride and longer service life
- BUY WITH CONFIDENCE -- Comes with Monroe’s Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee
- BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the DifferenceTM Guarantee
Product Attributes
9791 | LS39 |
9789 | XP4 |
Dust Shield Included | No |
9783 | No |
9908 | No |
9792 | No |
Part Description | Shock Absorber |
Compressed Length | 15.19 IN |
Extended Length | 24.32 in |
Gas Charged | Yes |
Lower Mount Type | Loop Bushing and Sleeve Mount - 1/2" Sleeve ID X 1.5/8" Sleeve OAL |
Parts Pack(s) | None |
Travel Length | 9.13 in |
Upper Mount Type | Cross Pin Mount - Closed Ended, 5/16" Hole ID (Both Ends) X 2.7/16" Pin Length (Hole Center to Center) |
Compressed Length | 385.8 MM |
Extended Length | 617.7 MM |
Travel Length | 231.9 MM |
Shock Absorber Rod End Measuring Point | Center of Cross Pin |
Shock Absorber Body End Measuring Point | Center of Loop |
Additional Information
MSDS Sheet Number | 1164 |
Country of Origin (Primary) | US |
Canadian Harmonizing Tariff Code | 8708803000 |
Harmonized Tariff Code (Schedule B) | 8708801600 |
Harmonized Tariff Code (HTS) | 8708801600 |
UPC | 00048598112217 |
VMRS Code | 016008003 |
UNSPSC | 25172011 |
Part Interchanges
- Chevrolet 19257310
- Chevrolet 20956377
- Chevrolet 20956378
- Chevrolet 20956379
- Chevrolet 20956380
- Chevrolet 23296352
- Chevrolet 23296353
- Chevrolet 25751136
- Chevrolet 25751137
- Chevrolet 25751138
- Chevrolet 25856173
- Chevrolet 25856175
- Chevrolet 84020664
- Chevrolet 84020665
- Chevrolet 84020666
- Chevrolet 84020667
- Chevrolet 84020668
- Chevrolet 84020673
- Chevrolet 84301663
- Chevrolet 84301664
- Chevrolet 84301665
- Chevrolet 84301666
- Chevrolet 84301668
- Chevrolet 84303233
- Chevrolet 84303234
- Chevrolet 88982652
- GMC 19257310
- GMC 20956377
- GMC 20956378
- GMC 20956379
- GMC 20956380
- GMC 23296352
- GMC 23296353
- GMC 25751136
- GMC 25751137
- GMC 25751138
- GMC 25856173
- GMC 25856175
- GMC 84020664
- GMC 84020665
- GMC 84020666
- GMC 84020667
- GMC 84020668
- GMC 84020673
- GMC 84301663
- GMC 84301664
- GMC 84301665
- GMC 84301666
- GMC 84301668
- GMC 84303233
- GMC 84303234
- GMC 88982652
- OEM 84020668
- OEM 25856175
- OEM 20956380
- ACDelco 520401
- Bilstein 24221948
- KYB KG5188
- OEM 84020667
- OEM 20956379
- ACDelco 530443
- KYB 344483
- Unity 251220
- ACDelco 5601111
- ACDelco 560677
- Gabriel 61687
- Gabriel G63897
- Autopart International 2701424145
- Autopart International 2725539653
- General Motors 20956379
- General Motors 20956380
- General Motors 25856175
- General Motors 84020667
- General Motors 84020668
- General Motors 84301668
- OSC S349009
- NAPA Shocks 76532
- AL-KO Xtreme 813103
- PRT 170197
- PM Auto PM6001136
- FCS 342525
- KYB 3450017
- FCS 342526
- KYB 565033
- KYB 349009
- KYB 554348
- KYB 565034
- KYB 565061
- KYB 344262
- KYB 344263
- KYB 344273
- Duralast MS3431712B
- NAPA Proformer SH81789
- General Motors 84301667
- MasterPro Shocks and Struts GM120
MONROE 34532 Cross Reference
We have 12 alternatives for the 34532 by MONROE:
Fits Vehicles
- GMC Savana 4500 (2009-2022)
- Chevrolet Express 4500 (2009-2022)
- GMC Savana 3500 (2003-2023)
- Chevrolet Express 3500 (2003-2024)
