MONROE part description

Product Description

Reflex Suspension Strut

Features & Benefits

  • IMPROVES STABILITY -- ASD (Acceleration Sensitive Damping) valving technology adjusts to impacts, reducing roll and dive for vehicles with a higher center of gravity
  • EXCEPTIONAL HANDLING -- Rod displaced valving, tuned specifically to each vehicle, adjusts to road extremes to provide consistency and a smooth ride (on most applications)
  • CONTROL AND DURABILITY -- Fluon-banded piston provides consistent sealing between piston and pressure tube for better control and increased durability
  • IMPROVES PERFORMANCE -- Nitrogen gas charge maintains tire-to-road contact for improved ride and handling by reducing aeration
  • CONSISTENT RIDE -- OE all-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown
  • OPTIONAL DUST BOOT/JOUNCE BUMPER -- Protective dust boot reduces dirt and moisture, while jounce bumper helps prevent severe suspension movement (both sold separately)
  • LONGER SERVICE LIFE -- Bronze reinforced rod guide bearing and special single lip seal combined with hardened, chrome-plated piston rod provides durability and longer service life
  • BUY WITH CONFIDENCE -- Comes with Monroe's Limited Lifetime Warranty and exclusive Feel the Difference™ Guarantee

Product Attributes

Compressed Length 15.4375 IN
Extended Length 21.625 in
Travel Length 6.187 in
Body Length 14.8125 IN
Body Type SS4
Dust Shield Included No
9783 No
9908 No
Strut Charging Type Gas Charged Unit - Strut Rod Will Extend Automatically
Parts Pack(s) P01746
Mounting Hardware Included Yes
Compressed Length 392.1 MM
Extended Length 549.3 MM
Travel Length 157.1 MM
Gas Charged Yes
Body Length 376.2 MM

Additional Information

MSDS Sheet Number 1164
Country of Origin (Primary) US
Canadian Harmonizing Tariff Code 8708801910
Harmonized Tariff Code (Schedule B) 8708801300
Harmonized Tariff Code (HTS) 8708801300
UPC 00048598039422
UNSPSC 25172007

Part Interchanges

MONROE 72292 Cross Reference

We have 2 alternatives for the 72292 by MONROE:

Fits Vehicles

  • Ram 1500 Classic (2019-2024)
  • Ram 1500 (2011-2021)
  • Dodge Ram 1500 (2009-2010)
