Centric 120.66056 - Centric Premium Brake Rotor
$6849
MSRP: $83.64
Save: $15.15
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric Premium Brake Rotor
Features & Benefits
- Symmetric vane; split-core castings for uniform heat distribution. Black E-Coat anti-corrosive coating protects much better than competitors spray paint. Double disc ground friction surface for optimal performance and serviced life
Product Attributes
| Disc Mounting [cntrc] | Behind the Hub |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Kgs | 6.820 |
| Vane Style [cntrc] | Straight |
| Misc Holes [cntrc] | 0 |
| Weight [cntrc] Lbs | 15.000 |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 25.600 MM |
| Discard Thickness | 1.008 IN |
| Nominal Thickness | 26.900 MM |
| Nominal Thickness | 1.059 IN |
| Hat Finish | Coated |
| Overall Height | 39.900 MM |
| Overall Height | 1.571 IN |
| Outside Diameter | 280.000 MM |
| Outside Diameter | 11.024 IN |
| Mounting Bolt Hole Quantity | 6 |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bolt Thread Pitch | 1.250 MM |
| Bearings Included | No |
| Center Hole Diameter | 3.626 IN |
| Center Hole Diameter | 92.100 MM |
| Mounting Bolt Hole Circle Diameter | 112.000 MM |
| Mounting Bolt Hole Circle Diameter | 4.409 IN |
| Mounting Bolt Hole Diameter | 12.000 MM |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| UPC | 805890312413 |
Part Interchanges
- Raybestos Brakes 580216
- Raybestos Brakes 580216FZN
- Raybestos Brakes 580216R
- Neotek Premium Drums and Rotors 1072006GF
- BD180191
- BD126137
- BD126137E
- E125-71-061
- BR5509002
- 55090
- 55090G
- 8890403740
- 89040374
- 145509
- 880216
- AR8651
- E12571061
- 55090HC
- 120.66056
- 55090GT
- 18041865
- YH145509
- 1407-26858
- 27375
- 2055090
- 18A1622A
- 19241830
- 1770901
- 90048049
CENTRIC 120.66056 Cross Reference
We have 7 alternatives for the 120.66056 by CENTRIC:
Fits Vehicles
- Isuzu i-350 (2006)
- Isuzu i-280 (2006)
- Isuzu i-370 (2007-2008)
- Isuzu i-290 (2007-2008)
- GMC Canyon (2004-2008)
- Chevrolet Colorado (2004-2008)
