WEBB part description

DRUM-BRAKE 16.5X5, 8.78 PILOT

DRUM INFORMATION
Drum Part Number: 65710B
Weight: 97
Brake Shoe Width: 5
Back Plate Thickness: 0.50
Drum Type:

Mount: Outboard
Brake Surface Diameter: 16.50
Overall Depth: 9.04
Brake Surface Flat: 5.95
Pilot Diameter: 8.78
Bolt Circle Diameter: 11.25
Bolt Hole (Number): 10
Bolt Hole Size: 1.31
Maximum Wear Diameter: 16.62
Notes:

WEBB DB1655B Cross Reference

We have 1 alternatives for the DB1655B by WEBB:

In business since 1946, Webb® has been a trusted brand for high-quality brake and wheel hub components in the heavy duty transportation industry. The company maintains an extensive catalog of OEM and aftermarket brake drums, brake rotors and calipers, and wheel hubs for Class 6, 7, and 8 trucks and heavy duty trailers. Each Webb product is made of premium materials and engineered for reduced weight without compromising structural strength or balance. All parts are also manufactured using the latest innovations, including advanced wear indicators and cool running vent technology to help minimize wear and make maintenance and repairs easier. Combined with a first-class customer service and after-sales support, customers can count on Webb products to keep their trucks running safely and smoothly for years to come.
