LuK LFW269 - lfw269
$11549
5 day lead time
limited availability at this price!
. Learn more
LUK part description
Product Description
LuK Rigid Flywheel
Application Summary
Subaru Legacy 2005-2006 (H4, 2.5L), Subaru Outback 2005-2006 (H4, 2.5L)
Product Attributes
| Ring Gear Major Dia. | 12.402 inch |
| Ring Gear Major Dia. | 315 mm |
| Flange Thickness | 0.626 inch |
| Flange Thickness | 15.9 MM |
| Flywheel matches Clutch | Flywheel matches Clutch |
| Ring Gear Mounting O.D. | 11.394 inch |
| Ring Gear Mounting O.D. | 289.4 mm |
| Bolt Hole Pattern | 2 |
| Ring Gear Thickness | 0.438 inch |
| Ring Gear Thickness | 11.13 mm |
| Overall Casting O.D. | 11.882 inch |
| Overall Casting O.D. | 301.8 mm |
| Has Dowel Pins | with Dowel Pins |
| Dowel hole diameter | 0.236 inch |
| Dowel hole diameter | 6 mm |
| Ring Gear Chamfer Side | Not available |
| Number of mounting bores | 24 |
| Crank Hole Dia. | 0.415 inch |
| Crank Hole Dia. | 10.55 mm |
| Flywheel friction surface outer diameter | 10.118 inch |
| Flywheel friction surface outer diameter | 257 mm |
| Ring Gear Chamfer Position @ 6:00 O´clock | Not available |
| Ring Gear Chamfer matches OE | Ring Gear Chamfer matches OE |
| Centering diameter / dowel hole | 10.551 inch |
| Centering diameter / dowel hole | 268 mm |
| Bolt hole PCD crankshaft | 2.591 inch |
| Bolt hole PCD crankshaft | 65.8 mm |
| Bolt hole PCD clutch pres.plte | 10.551 inch |
| Bolt hole PCD clutch pres.plte | 268 mm |
| Flywheel Friction Surface Inner diameter | 5.787 inch |
| Flywheel Friction Surface Inner diameter | 147 mm |
| Number of teeth, starter ring gear | 124 |
| Flywheel Thickness [mm] | 1.083 inch |
| Flywheel Thickness [mm] | 27.5 mm |
| Crank To Friction Surface | 1.124 inch |
| Crank To Friction Surface | 28.56 mm |
| I.D. for Pilot | 1.252 inch |
| I.D. for Pilot | 31.8 mm |
| Dowel Hole Pattern | 5 |
Additional Information
| Remanufactured Part | N |
| Warranty Special | 12 months or 12,000 miles - whichever comes first |
| Harmonized Tariff Code (HTS) | 8483508080 |
| Stock Status | S |
| UPC | 670774568664 |
Part Interchanges
Fits Vehicles
- Subaru Outback (2005-2006)
- Subaru Legacy (2005-2006)
LuK® is a worldwide leader in manufacturing clutches, power steering pumps, dual-mass flywheels, and self-adjusting clutch and engine components for various vehicle applications. It was founded by brothers George and Wilhelm Schaeffler in 1965. Initially, it was established as a manufacturer of diaphragm spring clutches with a release system. But when it was acquired by Schaeffler Group, a globally known supplier of chassis, engine, and transmission components for automotive and industrial applications, the company has grown immensely. Currently, LuK has research and development centers, offices, and manufacturing plants around the world. It remains steadfast to its commitment to providing only the highest quality clutches and other transmission, steering, suspension, and engine components.
