Name: Reach Cooling 61-1550 Charge Air Cooler (CAC) - Aluminum
SKU: 611550
Price: 956.99 USD
Availability: InStock

REACH COOLING part description

Product Description

Charge Air Cooler (CAC) - Aluminum

Application Summary

2008-2011 T2000, 2011-2013 Kenworth T700, 2008-2013 Peterbilt 365, 2008-2015 Peterbilt 367, 2008-2010 Peterbilt 386, 2008-2011 Peterbilt 387, 2013-2015 Peterbilt 579, 2011-2015 Peterbilt 587

Features & Benefits

Deep Extrusion Header: Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion.
Flat Tube Wall Thickness: Flat tube wall thickness is no less than .55mm to maximize ability to withstand added pressure.
Reinforcement Rib: Tubes feature a reinforcing rib to increase material strength.
7 Layer Packaging: Each charge air cooler is packaged in a heavy duty, 7 layer corrugated box to ensure best protection during transit.
Header Plate Bond: We use a wider angle header plate bond to eliminate the risk of header cracking.
Reinforced Aluminum Alloy: Header reinforced with aluminum bronze to increase strength by 50%.
Reach charge air coolers are built to withstand the pressures of long hauls. From the product design to the package it is shipped in, every consideration is taken to ensure longevity and peak performance.

Product Attributes

Core Length	657.2 MM
Core Thickness	2 IN
Tank Material	Aluminum
Core Height	37.687 IN
Core Material	Aluminum
Outlet Outside Diameter	101 MM
Outlet Location	Upper Right
Inlet Outside Diameter	101 MM
Inlet Location	Upper Left
Core Height	958 MM
Core Thickness	51 MM
Core Length	25 7/8 IN
Type	Tube and Fin
Inlet Outside Diameter	4 IN
Outlet Outside Diameter	4 IN

Part Interchanges

Fits Vehicles

Peterbilt 587 (2011-2015)
Kenworth T700 (2011-2013)
Peterbilt 387 (2008-2011)
Kenworth T2000 (2008-2011)
Peterbilt 579 (2013-2015)
Peterbilt 386 (2008-2010)
Peterbilt 367 (2008-2015)
Peterbilt 365 (2008-2013)
