Delphi TC7615 - Control Arm and Ball Joint Assembly
$10749
In stock
limited availability at this price!
Pay over 3-12 months with . Learn more
DELPHI part description
Product Description
Control Arm and Ball Joint Assembly
Product Attributes
Item Grade | Standard Replacement |
Position(s) | Front Right Lower Forward |
Pre-Greased | Yes |
Grease Fitting Included | No |
Bushings Included | Yes |
Ball Joint Mounting Type | Machined |
Ball Joint Stud Type | Threaded |
Control Arm Construction | Casting/Forged |
Control Arm Material | Aluminum |
Mounting Hardware Included | Yes |
Mounting Hole Quantity | 1 |
Adjustable | No |
Greasable | No |
Control Arm Maximum Width | 6.102 IN |
Control Arm Maximum Width | 155.00 MM |
Control Arm Color | Gray |
Ball Joint Stud Length | 3.760 IN |
Ball Joint Stud Length | 95.50 MM |
Control Arm Maximum Length | 19.016 IN |
Control Arm Maximum Length | 483.00 MM |
Mounting Hole Diameter | 0.480 IN |
Mounting Hole Diameter | 12.20 MM |
Bushing Material | Rubber |
Thread Direction | Clockwise (Right) |
Bushing Color | Black |
Finish | Uncoated |
Dust Boot Included | Yes |
Ball Joint Included | Yes |
Grade Type | Premium |
Boot Material | Chloroprene Rubber (CR) |
Locking Nut Included | Yes |
Boot Color | Black |
Steering Type | Power |
Bearing Material | Plastic |
Dust Boot Material | Chloroprene Rubber (CR) |
Additional Information
Harmonized Tariff Code (HTS) | 8708807000 |
Warranty Special | Limited Lifetime |
Warranty Special UOM | LF |
Harmonized Tariff Code (Schedule B) | 8708806590 |
Country of Origin (Primary) | TR |
UPC | 00689604331873 |
VMRS Code | 016001001 |
UNSPSC | 25172013 |
Part Interchanges
Fits Vehicles
- BMW M6 (2006-2010)
- BMW 650i (2006-2010)
- BMW 645Ci (2004-2005)
