Name: Delphi TA5314 Tie Rod End
SKU: ta5314
Price: 27.99 USD
Availability: InStock

DELPHI part description

Product Description

Tie Rod End

Product Attributes

Position(s)	Right Inner
Item Grade	Standard Replacement
Length	267.00 MM
Color	Black
End 1 Gender	Male
End 2 Gender	Male
Pre-Greased	Yes
Grease Fitting Included	Yes
Dust Boot Included	Yes
Width	82.2 MM
Type	Bent
Mounting Hardware Included	Yes
End 2 Thread Diameter	0.687 IN
End 2 Thread Diameter	17.46 MM
Height	79.50 MM
Housing Material	Steel
36	0.787 IN
Tube Diameter	20.00 MM
Adjustable	No
Greasable	Yes
Weight	1.94 lb
Cone Outside Diameter	15.90 MM
Bearing Material	Plastic
End 2 Thread Direction	Counterclockwise (Left)
Stud Type	Threaded
Length Stud Center to End	9.346 IN
Length Stud Center to End	237.40 MM
Dust Boot Material	Rubber
Tie Rod Material	Steel
End 2 Threads Per Inch	18
End 1 Threads Per Inch	20
End 1 Thread Diameter	0.437 IN
End 1 Thread Diameter	11.11 MM
Shank Length	15.90 MM
Stud Length	15.90 MM
Grade Type	Standard
Grade	Premium
Shank Length	0.626 IN
Stud Length	0.626 IN
662	0.626 IN

Additional Information

Harmonized Tariff Code (Schedule B)	8708998175
Country of Origin (Primary)	TR
Harmonized Tariff Code (HTS)	8708998180
Warranty Special	Limited Lifetime
Warranty Special UOM	LF
UPC	00689604289006
VMRS Code	015004019
UNSPSC	25174205

Part Interchanges

Fits Vehicles

Pontiac Ventura (1975-1977)
Pontiac Phoenix (1977)
Oldsmobile Omega (1975-1979)
Chevrolet Nova (1975-1979)
Chevrolet Camaro (1975-1981)
Buick Skylark (1975-1979)
Buick Apollo (1975)
