Delphi TA5224 - Tie Rod End
$2949
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Tie Rod End
Product Attributes
| Position(s) | Outer |
| Item Grade | Standard Replacement |
| Length | 137.00 MM |
| Color | Black |
| End 1 Gender | Male |
| End 2 Gender | Female |
| Pre-Greased | Yes |
| Dust Boot Included | Yes |
| Width | 42 MM |
| Type | Straight |
| Mounting Hardware Included | Yes |
| End 2 Thread Diameter | 0.630 IN |
| End 2 Thread Diameter | 16.00 MM |
| Height | 100.00 MM |
| Grade Type | Standard |
| Housing Material | Steel |
| 36 | 0.929 IN |
| Tube Diameter | 23.60 MM |
| Adjustable | No |
| Weight | 1.35 lb |
| Cone Outside Diameter | 18.00 MM |
| Bearing Material | Plastic |
| End 1 Thread Direction | Clockwise (Right) |
| End 2 Thread Direction | Clockwise (Right) |
| Stud Type | Threaded |
| End 2 Thread Pitch | 1.5 MM |
| Dust Boot Material | Rubber |
| Tie Rod Material | Steel |
| Shank Length | 18.00 MM |
| Stud Length | 18.00 MM |
| Grade | Premium |
| Shank Length | 0.709 IN |
| Stud Length | 0.709 IN |
| 662 | 0.709 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708998180 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Harmonized Tariff Code (Schedule B) | 8708998175 |
| Country of Origin (Primary) | TR |
| UPC | 00689604287194 |
| VMRS Code | 015004045 |
| UNSPSC | 25174205 |
Part Interchanges
Fits Vehicles
- Isuzu i-290 (2007-2008)
- Isuzu i-370 (2007-2008)
- GMC Canyon (2006-2012)
- Chevrolet Colorado (2006-2012)
- Isuzu i-280 (2006)
- Isuzu i-350 (2006)
