Centric 121.45090 - C-Tek Standard Brake Rotor
$3849
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
C-Tek Standard Brake Rotor
Features & Benefits
- Non-Directional Finishes. Machined non-friction surfaces. Widest application coverage in the aftermarket
Product Attributes
| Vane Style [cntrc] | Pillar |
| Misc Holes [cntrc] | 1 |
| Hat Id [cntrc] In | 5.039 |
| Weight [cntrc] Lbs | 13.300 |
| Disc Mounting [cntrc] | Floating |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Hat Id [cntrc] Mm | 128.000 |
| Weight [cntrc] Kgs | 6.040 |
| OEM Vane Count [cntrc] | 111 |
| Product Grade [cntrc] | Standard |
| Discard Thickness | 0.787 IN |
| Discard Thickness | 20.000 MM |
| Nominal Thickness | 0.866 IN |
| Stud/Lug Hole Diameter | 13.100 MM |
| Stud/Lug Hole Diameter | 0.516 IN |
| Stud/Lug Hole Quantity | 4 |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Center Hole Diameter | 2.165 IN |
| Center Hole Diameter | 55.000 MM |
| Bearings Included | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| ABS Tone Ring Included | No |
| Outside Diameter | 11.024 IN |
| Outside Diameter | 280.000 MM |
| Overall Height | 44.000 MM |
| Overall Height | 1.732 IN |
| Nominal Thickness | 22.000 MM |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708300050 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| UPC | 889590178746 |
Part Interchanges
CENTRIC 121.45090 Cross Reference
We have 2 alternatives for the 121.45090 by CENTRIC:
Fits Vehicles
- Mazda MX-5 (2016-2022)
- Mazda MX-5 Miata (2016-2023)
- Fiat 124 Spider (2018-2020)
