CENTRIC 320.45085 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.45085 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Hat Id [cntrc] In | 5.575 |
| Weight [cntrc] Kgs | 4.180 |
| Weight [cntrc] Lbs | 9.250 |
| Misc Holes [cntrc] | 1 |
| Hat Id [cntrc] Mm | 141.600 |
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Discard Thickness | 0.315 IN |
| Discard Thickness | 8.000 MM |
| Nominal Thickness | 0.394 IN |
| Nominal Thickness | 10.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 39.500 MM |
| Overall Height | 1.555 IN |
| Outside Diameter | 10.925 IN |
| Outside Diameter | 277.500 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Bearings Included | No |
| Center Hole Diameter | 2.681 IN |
| Center Hole Diameter | 68.100 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 13.300 MM |
| Stud/Lug Hole Diameter | 0.524 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590301359 |
CENTRIC 320.45085 Cross References
| Brand | Part Number |
|---|---|
| BREMBO | 08.C423.11 |
| RAYBESTOS | 981023, 981023R |
| Raybestos Brakes | 981023, 981023R |
