Centric 320.44174 - Centric GCX Rotor with Partial Coating
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 22.300 |
| Vane Style [cntrc] | Straight |
| Product Grade [cntrc] | Premium |
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Kgs | 10.140 |
| Misc Holes [cntrc] | 2 |
| Discard Thickness | 1.142 IN |
| Discard Thickness | 29.000 MM |
| Nominal Thickness | 31.800 MM |
| Nominal Thickness | 1.252 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 68.400 MM |
| Overall Height | 2.693 IN |
| Outside Diameter | 13.307 IN |
| Outside Diameter | 338.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 4.252 IN |
| Center Hole Diameter | 108.000 MM |
| Mounting Bolt Hole Circle Diameter | 139.400 MM |
| Mounting Bolt Hole Circle Diameter | 5.488 IN |
| Stud/Lug Hole Quantity | 6 |
| Stud/Lug Hole Diameter | 14.400 MM |
| Stud/Lug Hole Diameter | 0.567 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590301243 |
Part Interchanges
CENTRIC 320.44174 Cross Reference
We have 3 alternatives for the 320.44174 by CENTRIC:
