Centric 320.83013 - Centric GCX Rotor with Partial Coating
$12599
MSRP: $143.12
Save: $17.13
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
CENTRIC part description
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
Product Attributes
| Product Grade [cntrc] | Premium |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 39.500 |
| Notes [cntrc] | Hat Shaped, Cast in ABS Ring |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 17.950 |
| Disc Mounting [cntrc] | Behind the Hub |
| Misc Holes [cntrc] | 0 |
| Discard Thickness | 33.530 MM |
| Discard Thickness | 1.320 IN |
| Nominal Thickness | 36.600 MM |
| Nominal Thickness | 1.441 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 113.000 MM |
| Overall Height | 4.449 IN |
| Outside Diameter | 15.000 IN |
| Outside Diameter | 381.000 MM |
| Mounting Bolt Hole Quantity | 10 |
| ABS Tone Ring Included | Yes |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 5.992 IN |
| Center Hole Diameter | 152.200 MM |
| Mounting Bolt Hole Circle Diameter | 184.200 MM |
| Mounting Bolt Hole Circle Diameter | 7.252 IN |
| Mounting Bolt Hole Diameter | 14.900 MM |
| Mounting Bolt Hole Diameter | 0.587 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590297188 |
Part Interchanges
CENTRIC 320.83013 Cross Reference
We have 2 alternatives for the 320.83013 by CENTRIC:
