A-1 Cardone 1A-14006 - Rack and Pinion Assembly
- Part Number
- 1A-14006
- Manufacturer
- A-1 CARDONE
- Description
-
Rack and Pinion Assembly
details
We cannot fulfill orders for this part at this time. Please check back later or request a stock notification to receive an email.
Sometimes we may have similar parts for sale, click the button below to see if anything matches.
A-1 CARDONE part description
Product Description
Rack and Pinion Assembly
Application Summary
Audi A3 2009-06, A3 Quattro 2009-06; Volkswagen Bora 2010-05, Eos 2008-07, GTI 2009-06, Jetta 2008-06, Passat 2008-06, R32 2008, Rabbit 2009-06
Features & Benefits
- 100% replacement of rubber sealing components.
- Application of specialized lubricant(s) for extended life.
- Finished in protective coating to prevent corrosion and rust.
- Each unit undergoes a factory test drive, simulating extreme operating conditions while verifying all on-car communications.
- As a remanufactured Original Equipment part, this unit guarantees a perfect vehicle fit.
Rack and Pinion, Rack and Pinion Complete Unit, Complete Rack, Electronic Rack and Pinion, Rack, ERP, EPS, Steering Gear
Product Attributes
| Casting Material | Aluminum |
| Package Contents | EPS |
| Product Condition | Remanufactured |
| Mounting Brackets Included | No |
| Tie Rod Ends Included | Yes |
| Total Turns Lock to Lock | 2.90 |
| Grade Type | Regular |
| E-waste | Yes |
| Rack Length (mm) | 1279.53 |
| Thread Length (In) | 2.53 |
| Distance Between Mounting Holes (in) | 20.75 |
| Input Shaft Diameter (in) | 0.59 |
| Input Shaft Diameter (mm) | 14.99 |
| Input Shaft Length (in) | 2.28 |
| Rack Length (in) | 50.38 |
| Features and Benefits | Finished in protective coating to prevent corrosion and rust |
| Gasket or Seal Included | No |
| Outer Tie Rods Included | No |
| Bellows Color | Black |
| Type | Electric |
| Steering Input Shaft Spline Quantity | 22 |
| End To End Length | 50.38 IN |
| 6511 | 1279.02 MM |
| Gasket Or Seal Included | No |
| Grade Type | Regular |
| Inner Tie Rods Included | Yes |
| Mounting Brackets Included | No |
| Mounting Hardware Included | No |
| Mounting Hole Quantity | 4 |
| Outer Tie Rods Included | No |
| 6514 | 0.59 IN |
| Steering Input Shaft Diameter | 14.98 MM |
| Steering Input Shaft Spline Quantity | 22 |
| Bellows Color | Black |
| Total Turns Lock To Lock | 2.90 |
| Type | Electric |
| Input Shaft Type | Single Flat |
| Contains Electronic Components | Circuit Board |
| Does it require SDS | No |
| Is Item A Chemical | No |
| Is Or Contains A Battery | No |
| Is Or Contains A Bulb | No |
| Is Prop Sixty Five Affected | No |
| Is the item CARB affected | No |
| FAQ_Q1 | What do you replace on the rack? |
| FAA_A1 | Rubber seals, dust boots, wear items, lubricant(s), clamps and bearings are replaced 100%. Dampers, lock washers and drive belts are replaced where applicable. |
| FAQ_Q2 | Are the racks the same design as my original? |
| FAA_A2 | Yes, all units produced are verified to function to O.E. design specifications. Potential O.E. failure modes are evaluated and validated improvements are made. |
| FAQ_Q3 | Are there any precautions before I install? |
| FAA_A3 | Yes, the steering wheel must be held in a straight-ahead position using a suitable tool to prevent rotation while the intermediate shaft is disconnected from the rack and pinion. Failure to do so can result in damage to the clock spring within the steering column. If rotation of the intermediate shaft is suspected, the clock spring must be removed and re-centered. |
| FAQ_Q4 | Do I have to do any type of relearn after installation? |
| FAA_A4 | Yes, these systems are equipped with torque angle sensors in the steering column that need to be recalibrated after installation of the replacement rack and pinion. |
| FAQ_Q5 | Can I install one of your racks on my custom or classic vehicle? |
| FAA_A5 | Not recommended; radical modifications would be needed for installation of a modern electronic steering rack and pinion on a vehicle other than the O.E .Manufacturer intended application. |
Additional Information
| Remanufactured Part | Y |
| Warranty Distance | 36000 |
| Warranty Distance UOM | DH |
| Warranty Special UOM | TX |
| Warranty Time | 36 |
| Warranty Time UOM | MO |
| Country of Origin (Primary) | US |
| Harmonized Tariff Code (Schedule B) | 8708948000 |
| Harmonized Tariff Code (HTS) | 8708947550 |
| Canadian Harmonizing Tariff Code | 8708949900 |
| UPC | 00884548241220 |
Part Interchanges
Fits Vehicles
- Audi A3 Quattro (2006-2009)
- Volkswagen Bora (2005-2010)
- Volkswagen GTI (2006-2009)
- Volkswagen R32 (2008)
- Volkswagen Eos (2007-2008)
- Volkswagen Rabbit (2006-2009)
- Volkswagen Passat (2006-2008)
- Volkswagen Jetta (2006-2008)
- Audi A3 (2006-2009)
