Name: A-1 Cardone 52-7398 Remanufactured Power Brake Booster - Hydroboost, Black, Aluminum, without Master Cylinder
SKU: 527398
Price: 305.49 USD
Availability: InStock

A-1 CARDONE part description

HYDROBOOST

Product Description

Power Brake Booster

Application Summary

Chevrolet B7 2002-97, C6500 Kodiak 2002-97, C7500 Kodiak 2002-97, T6500 2009 2005-04 2002-97, T7500 2009 2005-04 2002-97; GMC B7 2002-97, C6500 Topkick 2002-97, C7500 Topkick 2002-97, T6500 2009 2005-04 2002-97, T7500 2009 2005-04 2002-97; Isuzu FSR 2002-00, FTR 2010-09 2002-00, FVR 2010-09 2002-00, FXR 2010-08

Features & Benefits

100% O.E. quality seals are installed on every unit for like-new performance and reliability.
Protective coating prevents corrosion and extends product life.
Master cylinder output rods are pre-adjusted (when included) for quick and easy installation.
All units are 100% tested to ensure reliable performance.
Guaranteed fit and function.

Power Brake Booster, Booster, Hydraulic Booster, Hydro Boost, Hydro Booster

Product Attributes

Color	Black
Package Contents	Hydro Boost; Instruction Sheet; Sealing Kit
Product Condition	Remanufactured
Material	Aluminim
Master Cylinder Included	No
Master Cylinder Stud Thread Size	10x1.5
E-waste	No
Features and Benefits	Remanufactured to match O.E. performance.
Booster Type	Hydraulic
Brake Pedal Rod Extension Included	No
Brake Service Grade	Regular
Gasket Or Seal Included	Yes
1928	59.41 MM
Housing Diameter	2.339 IN
Housing Material	Aluminim
Master Cylinder Included	No
9660	10x1.5
Mounting Bracket Included	Yes
Mounting Hardware Included	No
9659	No
Stud Thread Size	10x1.5
FAQ_Q1	What types of vehicles are hydraulic boosters used on?
FAA_A1	Hydraulic boosters are most commonly used on heavy duty pickup trucks and industrial applications. However, hydraulic boosters can be found on passenger vehicles as well.
FAQ_Q2	What type of fluid does a hydraulic booster require?
FAA_A2	As part of the power steering system, hydraulic boosters require O.E. power steering fluid.
FAQ_Q3	Will I need to retain my master cylinder pushrod?
FAA_A3	Yes, the master cylinder pushrod, spring and retainer will need to be retained and reused on the replacement hydraulic booster.
FAQ_Q4	How much PSI of power steering pressure should a hydraulic booster have?
FAA_A4	The hydraulic booster is designed to operate within the pressure range of the power steering system. In most cases this is at least 1200 PSI (deadhead pressure).
FAQ_Q5	Will I need to bleed my power steering system after installation?
FAA_A5	Yes, since the power steering lines have been removed, the system has been subjected to air. The power steering system will need to be bled using the O.E. bleeding procedure.
FAQ_Q6	What is the best way to identify a hydraulic booster?
FAA_A6	Most hydraulic boosters are equipped with a pedal rod identification number. These numbers are stamped on the end of the pedal rod near the eyelet. The pedal rod identification number is one of the most accurate ways to choose the correct replacement hydraulic booster.
FAQ_Q7	How can I test my hydraulic booster?
FAA_A7	A hydraulic booster can be tested just like a vacuum booster. With the engine off, pump the brake pedal until you feel firm resistance, then hold. Start the engine. Proper operation should result in the brake pedal slightly sinking.
FAQ_Q8	Does my hydraulic booster require flushing?
FAA_A8	Yes, the hydraulic booster should be flushed along with the power steering system. This should be done in accordance with the O.E. maintanence intervals.
FAQ_Q9	Can I convert my vehicle to a hydraulic boost system?
FAA_A9	This is possible, but not recommended. Altering or modifying a brake system puts the vehicle at higher risk of brake failure.
Contains Electronic Components	No
Does it require SDS	No
Is Item A Chemical	No
Is Or Contains A Battery	No
Is Or Contains A Bulb	No
Is Prop Sixty Five Affected	No
Is the item CARB affected	No

Additional Information

Remanufactured Part	Y
Warranty Distance	18000
Warranty Distance UOM	DH
Warranty Special UOM	TX
Warranty Time	12
Warranty Time UOM	MO
Country of Origin (Primary)	MX
Harmonized Tariff Code (HTS)	8708305090
Harmonized Tariff Code (Schedule B)	8708300050
Canadian Harmonizing Tariff Code	8708309990
UPC	00082617922562

Part Interchanges

Fits Vehicles

Isuzu FSR (2000-2002)
Isuzu FXR (2008-2010)
Isuzu FVR (2000-2002, 2009-2010)
Isuzu FTR (2000-2002, 2009-2010)
GMC C6500 Topkick (1997-2002)
GMC B7 (1997-2002)
GMC C7500 Topkick (1997-2002)
Chevrolet B7 (1997-2002)
Chevrolet C7500 Kodiak (1997-2002)
Chevrolet C6500 Kodiak (1997-2002)
GMC T7500 (1997-2002, 2004-2005, 2009)
Chevrolet T7500 (1997-2002, 2004-2005, 2009)
GMC T6500 (1997-2002, 2004-2005, 2009)
Chevrolet T6500 (1997-2002, 2004-2005, 2009)
