Name: Reach Cooling 61-1034 Charge Air Cooler
SKU: 611034
Price: 924.49 USD
Availability: InStock

REACH COOLING part description

Product Description

Charge Air Cooler

Application Summary

Kenworth:97-2011 T2000/2002-2018 T800

Features & Benefits

7 Layer Packaging: Each charge air cooler is packaged in a heavy duty, 7 layer corrugated box to ensure best protection during transit.
Reinforced Aluminum Alloy: Header reinforced with aluminum bronze to increase strength by 50%.
Flat Tube Wall Thickness: Flat tube wall thickness is no less than .55mm to maximize ability to withstand added pressure.
Header Plate Bond: We use a wider angle header plate bond to eliminate the risk of header cracking.
Deep Extrusion Header: Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion.
Reach charge air coolers are built to withstand the pressures of long hauls. From the product design to the package it is shipped in, every consideration is taken to ensure longevity and peak performance.
Reinforcement Rib: Tubes feature a reinforcing rib to increase material strength.

Product Attributes

Core Row Quantity	1
Outlet Header Width	62 mm
Outlet Location	Upper Right
Core Thickness	56 MM
Outlet Outside Diameter	4 IN
Inlet Location	Upper Left
Inlet Outside Diameter	102 MM
Core Length	25 7/16 IN
Inlet Header Length	25 11/16 in
Core Height	39.562 IN
Inlet Header Width	62 mm
Outlet Header Length	25 11/16 in
Core Thickness	2.187 IN
Core Length	646.1 MM
Type	Harmonica-shaped tube
Core Height	1005 MM
Inlet Header Width	2 7/16 in
Outlet Header Length	652.5 mm
Outlet Header Width	2.437 in
Core Material	Aluminum
Outlet Outside Diameter	102 MM
Inlet Header Length	652.5 mm
Inlet Outside Diameter	4 IN

Additional Information

Country of Origin (Primary)	CN
UPC	06949521756246

Part Interchanges

REACH COOLING 61-1034 Cross Reference

We have 87 alternatives for the 61-1034 by REACH COOLING:

Fits Vehicles

Kenworth T800 (2002-2003, 2018)
Kenworth T2000 (1997-2011)
