Name: Reach Cooling 42-10048 FORD-STERLING L-LA-LN-LS-LT9000 CAT3306-N14 CUMMINS-CAT 3406B-CAT3167-60 SERIES
SKU: 4210048
Price: 626.49 USD
Availability: InStock

REACH COOLING part description

Includes	One (1) Radiator
Core Material	Aluminum
Tank Material	Plastic
Thickness	1 7/8 (Inches)

Application Summary: Application Summary: Ford Models(1998-94) L Series, LN Series, LTL Series, LT9000 Series (1998-88); Freightliner Models: XB Line (2000-99), XB Raised Rail (2007), XC (2005)

Make	Ford
Model	L, LN, LTL, CL
Year	1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998

Product Description

FORD-STERLING L-LA-LN-LS-LT9000 CAT3306-N14 CUMMINS-CAT 3406B-CAT3167-60 SERIES

Application Summary

FORD-STERLING L-LA-LN-LS-LT9000 CAT3306-N14 CUMMINS-CAT 3406B-CAT3167-60 SERIES DETROIT DIESEL 11.1L

Features & Benefits

Our fin edges are folded for increased stability and heat disbursement properties.
Radiators are the foundation of any engine cooling system. Tasked with preventing the vehicle from overheating, the radiator is vital to keeping vehicles up and running.
Thermal expansion cuts allow for longer life and reduce failure rates by allowing improved core expansion and contraction during normal heat cycles.
We design and manufacture all our radiators to meet or even exceed Original Equipment specifications. We take pride in producing the most reliable replacement parts in the market.
Our included "multi-fit" attachments allow one radiator to cover multiple vehicle applications without sacrificing OE fit. This results in wider vehicle coverage with substantially less inventory.
We use longer header tabs for increased pressure resistance. This reduces the potential for tank to header leaks.
Deep extrusion headers provide a stronger tube-to-header joint that is more resistant to the effects of vibration and thermal tube expansion.
Our deep extrusion header provides a stronger tube to header joint which is more resistant to the effects of vibration and thermal tube expansion, virtually eliminating tube to header leaks.
Thermal expansion reduce failure rates by allowing improved core expansion and contraction.
Folded fin edges increase stability and heat disbursement properties.
Reach utilizes longer header tabs for increased pressure resistance, this reduces the potential for tank-to-header leaks.
Reach B-Type tubes feature central reinforcement to provide greater tolerance to pressure reducing the probability of tube failure.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.
Our B-Type tubes feature central reinforcement to provide greater tolerance to pressure. Stronger tube design means drastically reduced probability of tube failure.

Product Attributes

Inlet Header Length	725.8 MM
Outlet Header Length	725.5 MM
Transmission Oil Cooler Included	No
Outlet Header Width	3 IN
Engine Oil Cooler Included	No
Core Thickness	1.875 IN
Tank Material	Plastic
Inlet Header Width	76.3 MM
Core Row Quantity	2
Inlet Diameter	2.5 IN
Core Material	Aluminum
Core Height	37.375 IN
Core Width	27.5 IN
Frame Included	No
Down Flow Or Cross Flow Type	Cross Flow
Outlet Diameter	2 1/2 IN
Outlet Diameter	63.5 MM
Core Thickness	47.625 MM
Inlet Header Length	725.474 mm
Outlet Diameter	63.5 MM
Radiator Cap Included	No
Inlet Header Width	76.2 mm
Outlet Header Width	76.2 mm
Outlet Header Length	28 9/16 IN
Inlet Header Width	3 IN
Core Width	698.5 MM
Inlet Header Length	28.562 IN
Outlet Header Width	76.3 MM
Inlet Diameter	63.5 MM
Inlet Diameter	63.5 mm
Core Width	698 MM
Inlet Location	Upper Left
Core Height	949.325 MM
Outlet Header Length	725.474 mm
Core Height	949 MM
Core Thickness	48 MM
Outlet Location	Lower Right

Additional Information

Warranty Special	12 Months
Country of Origin (Primary)	CN
UPC	06949521787165
VMRS Code	042002001
UNSPSC	25174002

Part Interchanges

REACH COOLING 42-10048 Cross Reference

We have 142 alternatives for the 42-10048 by REACH COOLING:

Fits Vehicles

Freightliner XC Straight Rail (2005-2020)
Freightliner XC Raised Rail (2005-2020)
Freightliner XC Modular Rail (2008-2020)
Freightliner XC Formed Rail (2005-2007)
Freightliner XB Straight Rail (2007-2011)
Freightliner XB Raised Rail (2005-2008)
Freightliner XB Line (1999-2001, 2009-2015)
Freightliner XC (2001-2005)
Ford FT900 (1996)
Ford LTL9000 (1994-1997)
Ford LNT9000 (1994-1997)
Ford LN9000 (1994-1997)
Ford LTLS9000 (1994-1997)
Ford LTS9000 (1994-1997)
Ford LTLA9000 (1994-1996)
Ford LTA9000 (1994-1997)
Ford LT9000 (1994-1997)
Ford LS9000 (1994-1995)
Ford LLA9000 (1996-1997)
Ford LA9000 (1994-1997)
Ford L9000 (1994-1996)
Ford LN8000 (1994-1996)

Founded in 1999, Reach Cooling® is a worldwide leader in the manufacture and distribution of aftermarket cooling products for light, medium, and heavy duty truck applications. Its fasting-growing division is within its medium and heavy duty truck part sector, offering more than 30 HD condensers, more than 50 HD charge air coolers, and more than 100 HD radiators. All these products are manufactured to meet the highest OE standards to fit some of the most popular US truck makes, including Peterbilt, Mack, International, Isuzu, GMC, Ford, and Freightliner. Headquartered in Miami, Florida, Reach Cooling is fully committed to providing customers with only the best products, most competitive prices, and exceptional service.
