(888) 312-8812 Login SignupDELPHI TC3298 Control Arm and Ball Joint Assembly
Tap to view 20 more
MSRP: $279.43
$24449
Save $34.94
Limited availability at this price!
In Stock
Get it by Friday, Dec 19
DELPHI TC3298 Part Description
DELPHI TC3298 Specifications
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Right Lower |
| Pre-Greased | Yes |
| Grease Fitting Included | No |
| Ball Joint Stud Type | Threaded |
| Control Arm Material | Steel |
| Mounting Hole Quantity | 1 |
| Adjustable | No |
| Greaseable | No |
| Control Arm Color | Black |
| Ball Joint Thread Diameter | 0.630 IN |
| Ball Joint Thread Diameter | 16.00 MM |
| Ball Joint Stud Length | 1.094 IN |
| Ball Joint Stud Length | 27.80 MM |
| Control Arm Maximum Length | 17.638 IN |
| Control Arm Maximum Length | 448.00 MM |
| Bushing Material | Rubber |
| Mounting Hole Diameter | 0.571 IN |
| Mounting Hole Diameter | 14.50 MM |
| Thread Direction | Clockwise (Right) |
| Bushing Color | Black |
| Finish | Painted |
| Bushings Included | Yes |
| Dust Boot Included | Yes |
| Ball Joint Included | Yes |
| Mounting Hardware Included | Yes |
| Grade Type | Premium |
| Boot Material | Chloroprene Rubber (CR) |
| Locking Nut Included | Yes |
| Thread Diameter | 16.00 MM |
| Boot Color | Black |
| Steering Type | Power |
| Bearing Material | Plastic |
| Dust Boot Material | Chloroprene Rubber (CR) |
| Thread Diameter | 0.630 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| Country of Origin (Primary) | TR |
| UPC | 00689604272954 |
| VMRS Code | 016001001 |
| UNSPSC | 25172013 |
DELPHI TC3298 Part Interchanges
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-6426, 102-6426 |
| MOOG Chassis Products | CK620061, K500017, RK620061, 102-6426 |
| Mevotech | CMS86113 |
| Toyota | 48068-60010 |
| MAS Industries | CB74004, CB74004PR |
| Dorman | 521-434 |
| TRW | JTC2496 |
| N/A | GS86113 |
DELPHI TC3298 Fits Vehicles
- Toyota FJ Cruiser (2007-2009)
- Toyota 4Runner (2003-2009)
- Lexus GX470 (2003-2009)
