Delphi TC1665 - Ball Joint
$3849
MSRP: $57.11
Save: $18.62
In stock
limited availability at this price!
Pay over 3-12 months with
. Learn more
. Learn more
DELPHI part description
Product Description
Ball Joint
Product Attributes
| Item Grade | Standard Replacement |
| Position(s) | Front Lower |
| Material | Steel |
| Maximum Outside Diameter | 2.126 IN |
| Maximum Outside Diameter | 54.00 MM |
| Color | Gray |
| Stud Thread Diameter | 0.625 IN |
| Stud Thread Diameter | 15.8 MM |
| Castle Nut Included | Yes |
| Grease Fitting Included | Yes |
| Suspension Grade Type | Standard |
| Bushings Included | No |
| Dust Boot Included | Yes |
| Ball Joint Assembly | Yes |
| Width | 54 MM |
| Cotter Pin Included | Yes |
| Cotter Pin Hole | Yes |
| Mounting Hardware Included | Yes |
| Washers Included | No |
| Height | 4.705 IN |
| Height | 119.50 MM |
| Nuts Included | Yes |
| Mounting Hole Quantity | 0 |
| Adjustable | No |
| Greasable | Yes |
| 4966 | 1.102 IN |
| Stud Thread Length | 28 MM |
| Stud Type | Threaded |
| Mounting Type | Press-In |
| Dust Boot Material | Rubber |
| Mount Plate Included | No |
| Tapered Stud | Yes |
| 9212 | 0.827 IN |
| Stud Tapered End 2 Diameter | 21 MM |
| 9213 | 0.723 IN |
| Stud Tapered End 1 Diameter | 18.37 MM |
| Stud Threads Per Inch | 18 |
| Stud Thread Pitch | 0.7 MM |
| Length | 48.00 MM |
| Length | 1.890 IN |
Additional Information
| Harmonized Tariff Code (Schedule B) | 8708807000 |
| Country of Origin (Primary) | TR |
| Harmonized Tariff Code (HTS) | 8708806590 |
| Warranty Special | Limited Lifetime |
| Warranty Special UOM | LF |
| UPC | 00689604276808 |
| VMRS Code | 016001015 |
| UNSPSC | 25174203 |
Part Interchanges
Fits Vehicles
- Mazda B4000 (1994-1997)
- Mazda B3000 (1994-1997)
- Mazda B2300 (1994-1997)
- Mazda Navajo (1992-1994)
- Ford Ranger (1989-1997)
- Ford Explorer (1991-1994)
- Ford Bronco II (1989-1990)
