CENTRIC 320.58002 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.58002 Specifications
Product Attributes
| Weight [cntrc] Lbs | 17.000 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Max Pb Drum Dia [cntrc] Mm | 206.000 |
| Misc Holes [cntrc] | 0 |
| Max Pb Drum Dia [cntrc] In | 8.110 |
| Disc Mounting [cntrc] | Floating / DIH |
| Weight [cntrc] Kgs | 7.730 |
| Discard Thickness | 0.492 IN |
| Discard Thickness | 12.500 MM |
| Nominal Thickness | 14.100 MM |
| Nominal Thickness | 0.555 IN |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 66.400 MM |
| Overall Height | 2.614 IN |
| Outside Diameter | 12.598 IN |
| Outside Diameter | 320.000 MM |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Solid |
| Nominal Drum Diameter | 205.000 MM |
| Nominal Drum Diameter | 8.071 IN |
| Bearings Included | No |
| Center Hole Diameter | 2.831 IN |
| Center Hole Diameter | 71.900 MM |
| Mounting Bolt Hole Circle Diameter | 126.800 MM |
| Mounting Bolt Hole Circle Diameter | 4.992 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 16.200 MM |
| Stud/Lug Hole Diameter | 0.638 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590251845 |
