CENTRIC 320.51044 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.51044 Specifications
Product Attributes
| Hat Id [cntrc] In | 5.654 |
| Disc Mounting [cntrc] | Floating |
| Vane Style [cntrc] | Straight |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Weight [cntrc] Lbs | 14.800 |
| Hat Id [cntrc] Mm | 143.600 |
| Product Grade [cntrc] | Premium |
| Weight [cntrc] Kgs | 6.700 |
| Misc Holes [cntrc] | 2 |
| Discard Thickness | 21.400 MM |
| Discard Thickness | 0.843 IN |
| Nominal Thickness | 0.906 IN |
| Nominal Thickness | 23.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 44.500 MM |
| Overall Height | 1.752 IN |
| Outside Diameter | 280.000 MM |
| Outside Diameter | 11.024 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.717 IN |
| Center Hole Diameter | 69.000 MM |
| Mounting Bolt Hole Circle Diameter | 114.300 MM |
| Mounting Bolt Hole Circle Diameter | 4.500 IN |
| Stud/Lug Hole Quantity | 5 |
| Stud/Lug Hole Diameter | 12.600 MM |
| Stud/Lug Hole Diameter | 0.496 IN |
Additional Information
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| Country of Origin (Primary) | CN |
| UPC | 889590251821 |
CENTRIC 320.51044 Cross References
| Brand | Part Number |
|---|---|
| BREMBO | 09.C249.11, 09.D626.11 |
| N/A | 90003038, HC31584X |
| RAYBESTOS | 980897FZN, 980897R, 980897R2 |
| Raybestos Brakes | 980897FZN, 980897R |
