CENTRIC 320.40023 Part Description
Manufacturer
Product Description
Centric GCX Rotor with Partial Coating
Features & Benefits
- RS200 Coating our exclusive corrosion resistant coating for longer life and good looks; Iron FormulationEnhanced iron and high carbon metallurgies means the right rotor for your car; Operational Efficiency Full coverage with 80% fewer SKUs
CENTRIC 320.40023 Specifications
Product Attributes
| Disc Mounting [cntrc] | Floating |
| Weight [cntrc] Lbs | 10.500 |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 4.770 |
| Misc Holes [cntrc] | 4 |
| California Proposition 65 Text [cntrc] | WARNING: Cancer and Reproductive Harm |
| Product Grade [cntrc] | Premium |
| Discard Thickness | 19.000 MM |
| Discard Thickness | 0.748 IN |
| Nominal Thickness | 0.827 IN |
| Nominal Thickness | 21.000 MM |
| Disc Finish | Partially Coated |
| Hat Finish | Coated |
| Overall Height | 45.000 MM |
| Overall Height | 1.772 IN |
| Outside Diameter | 240.000 MM |
| Outside Diameter | 9.449 IN |
| ABS Tone Ring Included | No |
| Surface Type | Smooth |
| Solid Or Vented Type Rotor | Vented |
| Bearings Included | No |
| Center Hole Diameter | 2.402 IN |
| Center Hole Diameter | 61.000 MM |
| Mounting Bolt Hole Circle Diameter | 100.000 MM |
| Mounting Bolt Hole Circle Diameter | 3.937 IN |
| Stud/Lug Hole Quantity | 4 |
| Stud/Lug Hole Diameter | 12.800 MM |
| Stud/Lug Hole Diameter | 0.504 IN |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| NAFTA Preference Criterion Code | B |
| UPC | 889590250398 |
