(888) 312-8812 Login SignupRAYBESTOS 980728FZN Raybestos Element3 Coated Brake Rotor
MSRP: $125.05
$7649
Save $48.56
Limited availability at this price!
In Stock
Get it by Friday, Feb 13
RAYBESTOS 980728FZN Part Description
Manufacturer
Product Description
Raybestos Element3 Coated Brake Rotor
Application Summary
2016-2009 Toyota Venza Front
Features & Benefits
- Grey Fusion 4.0(R) Coating
- Grey Fusion 4.0® Coating
- Grey Fusion 4.0(R) coating provides optimal corrosion resistance and faster brake jobs.
- Grey Fusion 4.0® coating provides optimal corrosion resistance and faster brake jobs.
- RPT(R) Rust Prevention Technology
- RPT® Rust Prevention Technology
- RPT(R) Rust Prevention Technology for long lasting rust prevention.
- RPT® Rust Prevention Technology for long lasting rust prevention.
- Cooling Vanes
- Cooling vanes are coated to ensure vanes remain clear of rust and corrosion for optimal airflow and cooling.
- OE Matched
- OE Matched precision and performance.
- Non-Directional Finish
- A non-directional ground finish provides a product that is ready to install right out of the box.
RAYBESTOS 980728FZN Specifications
Product Attributes
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.44 IN |
| Center Hole Diameter | 62 MM |
| Conventional Or Drum-In-Hat Type Rotor | Conventional |
| Directional or Non-Directional Brake Surface | Non-Directional |
| Discard Thickness | 1.024 IN |
| Discard Thickness | 26 MM |
| Harmonize Code | 8708.30.5030 |
| Inside Diameter | 8.09 IN |
| Inside Diameter | 205.5 MM |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 4.5 IN |
| Mounting Bolt Hole Circle Diameter | 114.3 MM |
| Mounting Bolt Hole Diameter | 0.571 IN |
| Mounting Bolt Hole Diameter | 14.5 MM |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102 IN |
| Nominal Thickness | 28 MM |
| Outside Diameter | 12.756 IN |
| Outside Diameter | 324 MM |
| Overall Height | 1.94 IN |
| Overall Height | 49.3 MM |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
Additional Information
| Country of Origin (Primary) | CN |
| Harmonized Tariff Code (HTS) | 8708305030 |
| Canadian Harmonizing Tariff Code | 8708309990 |
| UPC | 00887213092813 |
RAYBESTOS 980728FZN Cross References
| Brand | Part Number |
|---|---|
| ADVANCE AUTO PARTS | 270083, YH270083, YH270083C, YH270083P |
| ADVICS | A6F023U |
| AUTOPARTSOURCE | 479775 |
| AUTOXTRA | AX900758 |
| AUTOZONE | 71915, 71915DG |
| BECK/ARNLEY | 083-3423 |
| BENDIX | PRT5912, PRTR5912 |
| BOSCH | 50011506 |
| BRAKEBEST | 50011506, 980728, 980728FZN, 980728R, 980728RGS |
| Brembo | 09.N431.11 |
| CENTRIC | 120.44168, 120.44168CRY, 121.44168, 126.44168SL, 126.44168SR, 127.44168L, 127.44168R, 320.44168, 320.44168F |
| Centric Parts | 120.44168, 120.44168CRY, 121.44168, 126.44168SL, 126.44168SR, 127.44168L, 127.44168R, 320.44168, 320.44168F |
| DURA CORP | BR31533, BR900758 |
| DuraGo | 900758, BR900758 |
| MONROE BRAKES | BD180270 |
| NEWTEK AUTOMOTIVE | 31533 |
| Newtek Automotive USA | 31533 |
| POWERSTOP | JBR1390EVC |
| PROMAX | 14-31533 |
| Qualis | 44647 |
| TOYOTA | 435120T010 |
| TopNotch | TN980728GEO |
| UAP | 2900758, R44168 |
| Ultra Brake | TO-6162 |
| WABCO | PS180270 |
| WABCO - Archived | PS180270 |
| WAGNER BRAKE | BD180270, BD180270E, BD180363 |
| WINHERE | 6621037 |
| WORLDPAC | 1407-270083, 1427-523976 |
RAYBESTOS 980728FZN Fits Vehicles
- Toyota Venza (2009-2016)
